Car Range

Alto

Exterior
Interiors
Comfort
Utility
Safety

Exterior

	STD (O)	LXI(O)	LXI(O)(CNG)	VXI	VXI+
Body Coloured Bumpers
Body Coloured Outside Door Handles
Wheel Covers	Center Cap	Full	Full	Full	Full
Body Side Molding

Interiors

	STD (O)	LXI(O)	LXI(O)(CNG)	VXI	VXI+
Dual Tone Interiors
B & C Pillar Upper Trims
C Pillar Lower Trim (Molded)
Seat Upholestry	Vinyl	Fabric + Vinyl	Fabric + Vinyl	Fabric + Vinyl	Fabric + Vinyl
Silver Accent Inside Door Handles
Silver Accent on Steering Wheels
Silver Accent on Louvers
Silver Accent on Center Garnish

Comfort

	STD (O)	LXI(O)	LXI(O)(CNG)	VXI	VXI+
Air Conditioner with Heater
Power Steering
Front Power Windows
Center Door Locking
Remote Keyless Entry
Audio (With USB, Aux-In & Radio)
Smartplay Dock
Smartplay Studio - 17.78 cm Touch Screen Infotainment System
Bluetooth Connectivity
Front Speaker (2) with Speaker Grille
Accessory Socket
Rear Parcel Tray
Assist Grips(Co - Dr. +Rear)
Digital Clock (In Speedometer Display)
Sun visor	Dr. +Co Dr.	Dr. +Co Dr.	Dr. +Co Dr.	Dr. +Co Dr.	Dr. +Co Dr.
RR Seat Head Rest - Integrated Type
Remote Back Door Opener
Internally Adjustable ORVM
Remote Fuel Lid Opener

Utility

	STD (O)	LXI(O)	LXI(O)(CNG)	VXI	VXI+
Front Console Bottle Holder
Rear Console Bottle Holder
Front Door Trim Map Pocket (Dr.)
Front Door Trim Map Pocket (Passenger)

Safety

	STD (O)	LXI(O)	LXI(O)(CNG)	VXI	VXI+
Headlight Levelling
RR Seat Belt ELR Type
High-Mounted Stop Lamp
Immobiliser
Front Wiper & Washer	2 Speed	2 Speed+Intermittent	2 Speed+Intermittent	2 Speed+Intermittent	2 Speed+Intermittent
Collapsible Steering Column
Tubeless Tyres
Rear Door Child Lock
Driver Side Airbag
Passenger Airbag
Reverse Parking Sensor
ABS with EBD
Seat Belt Reminder - Dr.+ Co - Dr.
Speed Alert System

Dimensions
Weight
Engine
Suspension System
Capacity
Tyres
Brakes

Dimensions

	STD (O)	LXI(O)	LXI(O)(CNG)	VXI	VXI+
Overall Length	3445 mm	3445 mm	3445 mm	3445 mm	3445 mm
Overall Width (Without Side Molding)	1490 mm	1490 mm	1490 mm	1490 mm	1490 mm
Overall Width (With side moulding)	1515 mm	1515 mm	1515 mm	1515 mm	1515 mm
Overall Height (Unladen)	1475 mm	1475 mm	1475 mm	1475 mm	1475 mm
Wheelbase	2360 mm	2360 mm	2360 mm	2360 mm	2360 mm
Tread (Front)	1295 mm	1295 mm	1295 mm	1295 mm	1295 mm
Tread (Rear)	1290 mm	1290 mm	1290 mm	1290 mm	1290 mm
Turning Radius	4.6 m	4.6 m	4.6 m	4.6 m	4.6 m

Weight

	STD (O)	LXI(O)	LXI(O)(CNG)	VXI	VXI+
Gross Weight	1185	1185	1185	1185	1185
Kerb Weight	732	757	850	762	762

Engine

	STD (O)	LXI(O)	LXI(O)(CNG)	VXI	VXI+
Swept Volume	796 cc	796 cc	796 cc	796 cc	796 cc
Engine Type	F8D	F8D	F8D	F8D	F8D
Number of Cylinders	3	3	3	3	3
Number of Valves	12	12	12	12	12
Maximum Power(petrol)	35.3 Kw @ 6000 rpm	35.3 Kw @ 6000 rpm	35.3 Kw @ 6000 rpm	35.3 Kw @ 6000 rpm	35.3 Kw @ 6000 rpm
Maximum Power(CNG)	30.1 kW @ 6000 rpm	30.1 kW @ 6000 rpm	30.1 kW @ 6000 rpm	30.1 kW @ 6000 rpm	30.1 kW @ 6000 rpm
Maximum Torque(Petrol)	69 Nm @ 3500 rpm	69 Nm @ 3500 rpm	69 Nm @ 3500 rpm	69 Nm @ 3500 rpm	69 Nm @ 3500 rpm
Maximum Torque(CNG)	60 Nm @ 3500 rpm	60 Nm @ 3500 rpm	60 Nm @ 3500 rpm	60 Nm @ 3500 rpm	60 Nm @ 3500 rpm
Transmission	5 Speed MT	5 Speed MT	5 Speed MT	5 Speed MT	5 Speed MT

Suspension System

	STD (O)	LXI(O)	LXI(O)(CNG)	VXI	VXI+
Front	Mac Pherson Strut	Mac Pherson Strut	Mac Pherson Strut	Mac Pherson Strut	Mac Pherson Strut
Rear	3-Link Rigid Axle Suspension	3-Link Rigid Axle Suspension	3-Link Rigid Axle Suspension	3-Link Rigid Axle Suspension	3-Link Rigid Axle Suspension

Capacity

	STD (O)	LXI(O)	LXI(O)(CNG)	VXI	VXI+
Seating	5 Persons	5 Persons	4 Persons	5 Persons	5 Persons
Fuel Tank	35 L	35 L	35 L(Petrol)/ 60 L (CNG)(Water Equivalent Filling Capacity)	35 L	35 L

Tyres

	STD (O)	LXI(O)	LXI(O)(CNG)	VXI	VXI+
Tyre Size	145/80 R12 (Tubeless)	145/80 R12 (Tubeless)	145/80 R12 (Tubeless)	145/80 R12 (Tubeless)	145/80 R12 (Tubeless)

Brakes

	STD (O)	LXI(O)	LXI(O)(CNG)	VXI	VXI+
Front	Disc	Disc	Disc	Disc	Disc
Rear	Drum	Drum	Drum	Drum	Drum

Alto K10

Interiors
Comfort & Convenience
Infotainment
Safety
Exteriors

Interiors

	STD MT	LXi MT	VXi MT	VXi AGS	VXi CNG	VXi+ MT	VXi+ AGS
Sun Visor	Dr.+Co Dr	Dr.+Co Dr	Dr.+Co Dr	Dr.+Co Dr	Dr.+Co Dr	Dr.+Co Dr	Dr.+Co Dr
Rear Parcel Tray
Assist Grips	Co- Dr.	Co- Dr.	Co- Dr. + Rear	Co- Dr. + Rear	Co- Dr. + Rear	Co- Dr. + Rear	Co- Dr. + Rear
Front console utility space
1L Bottle Holder in Front doors with Map Pockets
Silver Accent Inside Door Handles
Silver Accent on Steering Wheel
Silver Accent on Side Louvers
Silver Accent on Center Garnish

Comfort & Convenience

	STD MT	LXi MT	VXi MT	VXi AGS	VXi CNG	VXi+ MT	VXi+ AGS
Cabin Air Filter
Front Power Windows
Internally Adjustable ORVMs
Remote Keyless Entry
Remote Back Door Opener
Remote Fuel Lid Opener
Accessory Socket
Air Conditioner with Heater
Power Steering

Infotainment

	VXi MT	VXi AGS	VXi CNG	VXi+ MT	VXi+ AGS
Touch Screen Audio				17.78 cm (SmartPlay Studio)	17.78 cm (SmartPlay Studio)
Media Receiver (AM/FM/Bluetooth)	SmartPlay Dock	SmartPlay Dock	SmartPlay Dock	SmartPlay Studio	SmartPlay Studio
AUX Port
USB Port
Remote Application
Bluetooth
Android Auto
Apple Carplay
Speakers	2	2	2	4	4
Steering Mounted Audio & Voice Control
Digital Speedometer
Distance to Empty	^{*^}	^{*^}	^{*^}
Fuel Consumption - Average	^{*^}	^{*^}	^{*^}
Fuel Consumption - Instantaneous	^{*^}	^{*^}	^{*^}
Gear Shift Indicator (MT only)	(Petrol Variant Only)	(Petrol Variant Only)	(Petrol Variant Only)
Gear Position Indicator (AGS only)
Low Fuel Warning	SmartPlay Dock	SmartPlay Dock	SmartPlay Dock	SmartPlay Studio	SmartPlay Studio
Door Ajar Warning	SmartPlay Dock	SmartPlay Dock	SmartPlay Dock	SmartPlay Studio	SmartPlay Studio
Key off/Head lamp on Reminder
*^For VXI CNG variant, fuel consumption related data available only in Petrol Mode.

Safety

	STD MT	LXi MT	VXi MT	VXi AGS	VXi CNG	VXi+ MT	VXi+ AGS
Rear Door Child lock
Engine Immobiliser
Speed Sensing Auto Door Lock
Central Door Locking
Impact Sensing Door Unlock
High Speed Alert^{^}
Front Seat Belts Pre-Tensioner & Force Limiter
Rear Seat Belt Center(2-Point Static)			(Petrol Variant Only)	(Petrol Variant Only)	(Petrol Variant Only)
Rear Seat Belt Outboard(3-Point)	(Static)	(Static)	(ELR)	(ELR)	(ELR)	(ELR)	(ELR)
Dual Front Airbags^##
ABS with EBD
Reverse Parking Sensor
Seat Belt Reminder - Dr.+ Co - Dr.
HEARTECT Platform
Headlamp Levelling
High-Mounted Stop Lamp
Collapsible Steering Column
^The Speed Alert System gives audible warning for alert of over-speed to driver.
##For details on functioning of safety features,including air bag, kindly refer to the Owner's Manual.

Exteriors

	STD MT	LXi MT	VXi MT	VXi AGS	VXi CNG	VXi+ MT	VXi+ AGS
Roof Antenna
Body Coloured Bumpers
Body Coloured Outside Door Handles
Wheel Covers	Center Cap	Center Cap	Full	Full	Full	Full	Full

Dimensions
Engine
Transmission
Suspension
Brakes & Tyre

Dimensions

	STD MT	LXi MT	VXi MT	VXi AGS	VXi CNG	VXi+ MT	VXi+ AGS
Overall Length (mm)	3530	3530	3530	3530	3530	3530	3530
Overall Width (mm)	1490	1490	1490	1490	1490	1490	1490
Overall Height (Unladen) (mm)	1520	1520	1520	1520	1520	1520	1520
Wheelbase(mm)	2380	2380	2380	2380	2380	2380	2380
Turning Radius(m)	4.5	4.5	4.5	4.5	4.5	4.5	4.5
Seating Capacity	5 Persons	5 Persons	5 Persons	5 Persons	4 Persons	5 Persons	5 Persons
Boot Space(L)^#	214	214	214	214		214	214
#VDA method.

Engine

	STD MT	LXi MT	VXi MT	VXi AGS	VXi CNG	VXi+ MT	VXi+ AGS
Engine Type	K10C	K10C	K10C	K10C	K10C CNG	K10C	K10C
Fuel type	Petrol	Petrol	Petrol	Petrol	Petrol + CNG	Petrol	Petrol
Piston Displacement (cc)	998	998	998	998	998	998	998
Maximum Power (kW@rpm) (1 kW = 1.35962 PS)	49 kW @ 5500 rpm	49 kW @ 5500 rpm	49 kW @ 5500 rpm	49 kW @ 5500 rpm	41.7 kW @ 5300 rpm (CNG Mode) 48 kW @ 5500 rpm (Petrol Mode)	49 kW @ 5500 rpm	49 kW @ 5500 rpm
Maximum Torque (Nm@rpm)	89 Nm @ 3500 rpm	89 Nm @ 3500 rpm	89 Nm @ 3500 rpm	89 Nm @ 3500 rpm	82.1 Nm @ 3400 rpm (CNG Mode) 89 Nm @ 3500 rpm (Petrol Mode)	89 Nm @ 3500 rpm	89 Nm @ 3500 rpm
Emission Standard	BS VI	BS VI	BS VI	BS VI	BS VI	BS VI	BS VI
Fuel Tank Capacity(L)	27	27	27	27	27 (Petrol Mode) 55 (CNG Mode) (Water Equivalent)	27	27

Transmission

	STD MT	LXi MT	VXi MT	VXi AGS	VXi CNG	VXi+ MT	VXi+ AGS
Transmission Type	5MT/AGS	5MT/AGS	5MT/AGS	5MT/AGS	5MT	5MT/AGS	5MT/AGS

Suspension

	STD MT	LXi MT	VXi MT	VXi AGS	VXi CNG	VXi+ MT	VXi+ AGS
Front	Mac Pherson Strut with Coil Spring	Mac Pherson Strut with Coil Spring	Mac Pherson Strut with Coil Spring	Mac Pherson Strut with Coil Spring	Mac Pherson Strut with Coil Spring	Mac Pherson Strut with Coil Spring	Mac Pherson Strut with Coil Spring
Rear	Torsion Beam with Coil Spring	Torsion Beam with Coil Spring	Torsion Beam with Coil Spring	Torsion Beam with Coil Spring	Torsion Beam with Coil Spring	Torsion Beam with Coil Spring	Torsion Beam with Coil Spring

Brakes & Tyre

	STD MT	LXi MT	VXi MT	VXi AGS	VXi CNG	VXi+ MT	VXi+ AGS
Front	Disc	Disc	Disc	Disc	Disc	Disc	Disc
Rear	Drum	Drum	Drum	Drum	Drum	Drum	Drum
Tyre Size	145/80 R13	145/80 R13	145/80 R13	145/80 R13	145/80 R13	145/80 R13	145/80 R13

Celerio

Exteriors
Interiors
Comfort and Convenience
Central Console & Instrument Panel
Safety & Security
New Technology

Exteriors

	LXi MT	VXi MT	VXi CNG	ZXi MT	ZXi+ MT	VXi AGS	ZXi AGS	ZXi+ AGS
ORVM with Turn Indicators
Front Fog Lamps
Body Coloured Bumper
Body Coloured ORVMs
Body Coloured Outside Door Handles
Chrome accent on front grille
B Pillar Black Out Tape
Full Wheel Covers	(Center cap)
15" (38.02cm) Alloy Wheels

Interiors

	LXi MT	VXi MT	VXi CNG	ZXi MT	ZXi+ MT	VXi AGS	ZXi AGS	ZXi+ AGS
Co-Dr Vanity Mirror in Sun Visor
Dr. Side Sunvisor with ticket holder
Day Night IRVM
Front Cabin Lamp (3 Positions)
Bottle Holder	6	6	6	6	6	6	6	6
Driver Seat Height Adjuster
Front Seat Back Pockets (Passenger Side)
Rear Seat (60:40 split)
Front and Rear Headrest	Integrated	Integrated	Integrated	Integrated	Integrated	Integrated	Integrated	Integrated
Rear Parcel Shelf

Comfort &Convenience

	LXi MT	VXi MT	VXi CNG	ZXi MT	ZXi+ MT	VXi AGS	ZXi AGS	ZXi+ AGS
Air Conditioner(Manual)
Pollen Filter
Engine Push Start/Stop with Smart Key
Smartplay Studio System with Smartphone Navigation and Voice Command (Android Auto and Apple CarPlay enabled)
Smart Play Dock - USB, FM, AUX, BT
No. of Speakers				4	4		4	4
Remote keyless Entry
Security System
Central Door Lock (5 Doors)
Power Windows		Fr/Rr	Fr/Rr	Fr/Rr	Fr/Rr	Fr/Rr	Fr/Rr	Fr/Rr
Power Windows - Auto Down (Driver Side)
Outside Mirror Types	Flap Type	Electrically Adjustable	Electrically Adjustable	Electrically Adjustable	Electrically Adjustable	Electrically Adjustable	Electrically Adjustable	Electrically Adjustable
Electrically-Foldable ORVM
Steering- Mounted Audio Controls
Steering-Mounted Voice Control
Power Steering

Central Consol & Instrument Panel

	LXi MT	VXi MT	VXi CNG	ZXi MT	ZXi+ MT	VXi AGS	ZXi AGS	ZXi+ AGS
Illumination Colour	Amber	Amber	Amber	Amber	Amber	Amber	Amber	Amber
Tachometer
Urethane Steering Wheel
Tilt Steering
Accessory Socket
Dial-Type Climate Control	Black	Silver Painted	Silver Painted	Silver Painted	Silver Painted	Silver Painted	Silver Painted	Silver Painted
Fuel Consumption (Instantaneous and avg.)
Distance to Empty
Gear Position Indicator
Gear Shift Indicator
Door Ajar Warning Lamp
Headlamp Warning
Low Fuel Warning
Key Off/Headlamp on Reminder

Safety & Security

	LXi MT	VXi MT	VXi CNG	ZXi MT	ZXi+ MT	VXi AGS	ZXi AGS	ZXi+ AGS
Driver Airbag^##
Passenger Airbags^##
Seat Belt Reminder with Buzzer (Front + Rear Seat)^**#
Seat Belt Pre-Tensioner & Force Limiters (Dr. + Co-Dr.)
Seat Belt for all Seats
Hill Hold Assist
Impact-Sensing Auto Door Unlock
Pedestrian Protection
ABS with EBD
ESC
Speed-Sensitive Auto Door Lock
Headlight Leveling
Rear Window Wiper & Washer
Front Ventilated Disc
Immobilizer
Child-Proof Rear Door Locks
Rear Defogger
Speed Alert System^
Reverse Parking Assist Sensors
##For details on functioning of safety features, including air bag, kindly refer to the Owner's Manual.
**#Seat belt reminder comes on unless all rear passenger's seat belts are fastened irrespective of the presence or absence of passenger.
^The speed alert system gives audible warning for alert of over-speed to driver. When Vehicle speed exceeds 80km/h, primary level warning with two beeps will sound every minute. When the vehicle speed exceeds about 120 km/h, secondary level warning with continuous beeps will sound. If the vehicle speed is slowed down to about 118 km/h, primary warning will resume. If the vehicle is slowed down to about 78 km/h speed alert warning will stop. This buzzer does not indicate any malfunction in vehicle.

New Technology

	LXi MT	VXi MT	VXi CNG	ZXi MT	ZXi+ MT	VXi AGS	ZXi AGS	ZXi+ AGS
Engine Idle Start Stop		(Petrol)	(Petrol)
Hill Hold Assist

Dimensions (in mm)
Engine
Transmission
Suspension System
Weight(kg)
Capacity
Power Steering
Tyres
Brakes

Dimensions

	LXi MT	VXi MT	ZXi MT	ZXi+ MT	VXi AGS	ZXi AGS	ZXi+ AGS	VXi CNG
Overall Length	3695	3695	3695	3695	3695	3695	3695	3695
Overall Width	1655	1655	1655	1655	1655	1655	1655	1655
Overall Height	1555	1555	1555	1555	1555	1555	1555	1555
Wheelbase	2435	2435	2435	2435	2435	2435	2435	2435
Tread Front	1430(R14), 1440(R15)	1430(R14), 1440(R15)	1430(R14), 1440(R15)	1430(R14), 1440(R15)	1430(R14), 1440(R15)	1430(R14), 1440(R15)	1430(R14), 1440(R15)	1430(R14), 1440(R15)
Tread Rear	1440(R14), 1450(R15)	1440(R14), 1450(R15)	1440(R14), 1450(R15)	1440(R14), 1450(R15)	1440(R14), 1450(R15)	1440(R14), 1450(R15)	1440(R14), 1450(R15)	1440(R14), 1450(R15)

Engine

	LXi MT	VXi MT	ZXi MT	ZXi+ MT	VXi AGS	ZXi AGS	ZXi+ AGS	VXi CNG
Type	K10C	K10C	K10C	K10C	K10C	K10C	K10C	K10C CNG
Capacity	998cc	998cc	998cc	998cc	998cc	998cc	998cc	998cc
Engine Type	Aluminium	Aluminium	Aluminium	Aluminium	Aluminium	Aluminium	Aluminium	Aluminium
Number of Cylinders	3	3	3	3	3	3	3	3
Number of Valves in Each Cylinder	4	4	4	4	4	4	4	4
Maximum Output	49kW (66.62Ps) @ 5500rpm	49kW (66.62Ps) @ 5500rpm	49kW (66.62Ps) @ 5500rpm	49kW (66.62Ps) @ 5500rpm	49kW (66.62Ps) @ 5500rpm	49kW (66.62Ps) @ 5500rpm	49kW (66.62Ps) @ 5500rpm	CNG Mode: 41.7kW (56.70Ps) @ 5300rpm Gasoline Mode: 48kW (65.26Ps) @ 5500rpm
Maximum Torque	89Nm @ 3500rpm	89Nm @ 3500rpm	89Nm @ 3500rpm	89Nm @ 3500rpm	89Nm @ 3500rpm	89Nm @ 3500rpm	89Nm @ 3500rpm	CNG Mode: 82.1Nm @ 3400rpm Gasoline Mode: 89Nm @ 3500rpm
Emmision Standard Type	BS VI + OBD II	BS VI + OBD II	BS VI + OBD II	BS VI + OBD II	BS VI + OBD II	BS VI + OBD II	BS VI + OBD II	BS VI + OBD II
Accelerator Pedal Type	Electric Type	Electric Type	Electric Type	Electric Type	Electric Type	Electric Type	Electric Type	Electric Type

Transmission

	LXi MT	VXi MT	ZXi MT	ZXi+ MT	VXi AGS	ZXi AGS	ZXi+ AGS	VXi CNG
Type	5MT/Auto Gear Shift	5MT/Auto Gear Shift	5MT/Auto Gear Shift	5MT/Auto Gear Shift	5MT/Auto Gear Shift	5MT/Auto Gear Shift	5MT/Auto Gear Shift	5MT

Suspension System

	LXi MT	VXi MT	ZXi MT	ZXi+ MT	VXi AGS	ZXi AGS	ZXi+ AGS	VXi CNG
Front	Mac Pherson Strut with Coil Spring	Mac Pherson Strut with Coil Spring	Mac Pherson Strut with Coil Spring	Mac Pherson Strut with Coil Spring	Mac Pherson Strut with Coil Spring	Mac Pherson Strut with Coil Spring	Mac Pherson Strut with Coil Spring	Mac Pherson Strut with Coil Spring
Rear	Torsion Beam with Coil Spring	Torsion Beam with Coil Spring	Torsion Beam with Coil Spring	Torsion Beam with Coil Spring	Torsion Beam with Coil Spring	Torsion Beam with Coil Spring	Torsion Beam with Coil Spring	Torsion Beam with Coil Spring

Weight(kg)

	LXi MT	VXi MT	ZXi MT	ZXi+ MT	VXi AGS	ZXi AGS	ZXi+ AGS	VXi CNG
Kerb Weight	800kg	810kg	810kg	820kg	815kg	820kg	825kg	905kg
Gross Vehicle Weight	1260	1260	1260	1260	1260	1260	1260	1320

Capacity

	LXi MT	VXi MT	ZXi MT	ZXi+ MT	VXi AGS	ZXi AGS	ZXi+ AGS	VXi CNG
Seating Capacity \| Persons	5	5	5	5	5	5	5	5
Luggage Capacity (L)	313***	313***	313***	313***	313***	313***	313***
Fuel Tank Capacity (L)	32	32	32	32	32	32	32	Petrol:32 CNG:60(Water Equivalent)
***VDA Method

Power Steering

	LXi MT	VXi MT	ZXi MT	ZXi+ MT	VXi AGS	ZXi AGS	ZXi+ AGS	VXi CNG
Type	Electric Power Steering	Electric Power Steering	Electric Power Steering	Electric Power Steering	Electric Power Steering	Electric Power Steering	Electric Power Steering	Electric Power Steering

Tyres

	LXi MT	VXi MT	ZXi MT	ZXi+ MT	VXi AGS	ZXi AGS	ZXi+ AGS	VXi CNG
Tyre Size**	165/70R14	165/70R14	165/70R14	175/60R15	165/70R14	165/70R14	175/60R15	165/70R14
**Spare wheel material is steel (for all variants) and tyre size is 165/70 R14.

Brakes

	LXi MT	VXi MT	ZXi MT	ZXi+ MT	VXi AGS	ZXi AGS	ZXi+ AGS	VXi CNG
Front	Disc	Disc	Disc	Disc	Disc	Disc	Disc	Disc
Rear	Drum	Drum	Drum	Drum	Drum	Drum	Drum	Drum

Dzire

EXTERIOR
INTERIOR
SAFETY AND SECURITY
AUDIO AND ENTERTAINMENT
COMFORT & CONVENIENCE
TRANSMISSION

EXTERIOR

	LXi MT	VXi MT	VXi AMT	VXi CNG MT	ZXi MT	ZXi AMT	ZXi CNG MT	ZXi+ MT	ZXi+ AMT
LED Projector Headlamps
Daylight Running Lamps
Rear Combination LED Lamp
High Mounted LED Stop Lamp
Body Coloured Door Handles
Body Coloured ORVMs
Side Turn Indicators on ORVMs
Wheels (Steel/Alloy/Precision-cut Alloy)	Steel	Steel	Steel	Steel	Alloy	Alloy	Alloy	Precision Cut Alloy	Precision Cut Alloy
Wheel Cover
Door Outer-Weather Strip	Black	Black	Black	Black	Chrome	Chrome	Chrome	Chrome	Chrome

INTERIORS

	VXi MT	VXi AMT	ZXi+ MT	ZXi+ AMT
Leather Wrapped Steering Wheel
Modern Wood Accent With Natural Gloss Finish
Dual-Tone Interiors
Multi-Information Display			(Coloured)	(Coloured)
Outside Temperature Display	AMT Only	AMT Only
Low-Fuel Warning Lamp
Urbane Satin Chrome Accents on Console, Gear Lever and Steering Wheel
Front Dome Lamp
Tachometer
Front Door Armrest with Fabric
Co. Driver Side Sunvisor with Vanity Mirror
Driver Side Sunvisor with Ticket Holder

SAFETY AND SECURITY

	LXi MT	VXi MT	VXi AMT	VXi CNG MT	ZXi MT	ZXi AMT	ZXi CNG MT	ZXi+ MT	ZXi+ AMT
Suzuki HEARTECT body
ABS With EBD and Brake Assist
ESP with Hill Hold Assist (AMT Only)
Dual Airbags##
Reverse Parking Sensors
Reverse Parking Camera
Anti-theft Security System
Front Fog Lamps
Rear Defogger
ISOFix Child Seat Anchorages
Front Seat Belt with Pre-Tensioner
Pinch Guard Power Window (Driver)
Engine Immobilizer
Speed-Sensitive Door Locking
Night and Day Adjustable IRVM
^Speed Alert
Driver & Co-Driver Seat Belt Reminder
Key-Left Warning Lamp & Buzzer
Front Fog Lamp Garnish	Silver	Chrome	Chrome	Chrome	Chrome	Chrome	Chrome	Chrome	Chrome
Door Ajar Warning Lamp
^The speed alert system gives audible warning for alert of over-speed to driver. When vehicle speed exceeds about 80 Km/h, primary level warning with two beeps will sound every minute. When the vehicle speed about 120 Km/h, secondary level warning with continuous beeps will sound.If the Vehicle Speed is slowed down to about 118 km/h, primary warning will resume. If the vehicle is slowed down to about 78 km/h, speed alert warning will stop. This buzzer does not indicate any malfunction in vehicle.
##For details on functioning of safety features, including air bag, kindly refer to the Owner's Manual.

AUDIO AND ENTERTAINMENT

	ZXi MT	ZXi AMT	ZXi CNG MT	ZXi+ MT	ZXi+ AMT
All New Feather Touch Audio System
Smartplay Studio System with Navigation and Voice Command (Android Auto and Apple CarPlay enabled)
AHA Platform (Through Smartplay Studio App)
Audio Player with USB, CD, AUX and FM/AM with Bluetooth Connectivity
Steering Mounted Audio & Calling Controls
Audio Remote Control	(Through Smartplay Studio app)	(Through Smartplay Studio app)	(Through Smartplay Studio app)	(Through Smartplay Studio app)	(Through Smartplay Studio app)

COMFORT AND CONVENIENCE

	ZXi+ MT	ZXi+ AMT
Engine Push Start-Stop Button with Smart Key
Auto Headlamp (Lead me to vehicle/follow me home)
Rear AC Vent
Rear Seat Center Armrest with Cup Holder
Remote Keyless Entry System
Manual Air Conditioner with Heater
Automatic Climate Control
Pollen Filter
Front Accessory Socket
Rear Accessory Socket with Mobile Pocket
Central Locking
Electromagnetic Trunk Opening
Gear Shift Indicator (MT Only)
Power Windows (Front + Rear)
Electrically Adjustable ORVMs
Electrically Foldable ORVMs	(Key Sync)	(Key Sync)
Cruise Control
Driver Side Auto Down Power Window
Driver Side Auto Up Power Window
Tilt Steering
Height Adjustable Driver Seat
Adjustable Front Seat Headrests
Luggage Room Lamp
Bottle Holder on All Doors

TRANSMISSION

	LXi MT	VXi MT	VXi AMT	VXi CNG MT	ZXi MT	ZXi AMT	ZXi CNG MT	ZXi+ MT	ZXi+ AMT
Door Speakers (4 Speakers)
Tweeters
Antenna

DIMENSION
ENGINE
TRANSMISSION
BRAKES
STEERING
SUSPENSION
OTHERS

DIMENSIONS

	LXi MT	VXi MT	VXI AMT	VXI CNG MT	ZXI MT	ZXI AMT	ZXI CNG MT	ZXI+ MT	ZXI+ AMT
Length (mm)	3995	3995	3995	3995	3995	3995	3995	3995	3995
Width (mm)	1735	1735	1735	1735	1735	1735	1735	1735	1735
Height (mm)	1515(Unladen)	1515(Unladen)	1515(Unladen)	1515(Unladen)	1515(Unladen)	1515(Unladen)	1515(Unladen)	1515(Unladen)	1515(Unladen)
Wheelbase(mm)	2450	2450	2450	2450	2450	2450	2450	2450	2450
Boot Space (L)	378	378	378		378	378		378	378

ENGINE

	LXi MT	VXi MT	VXI AMT	VXI CNG MT	ZXI MT	ZXI AMT	ZXI CNG MT	ZXI+ MT	ZXI+ AMT
Engine Capacity	1197	1197	1197	1197	1197	1197	1197	1197	1197
Max Power (kW@rpm)	66 kW @ 6000rpm	66 kW @ 6000rpm	66 kW @ 6000rpm	57kW @ 6000 rpm	66 kW @ 6000rpm	66 kW @ 6000rpm	57kW @ 6000 rpm	66 kW @ 6000rpm	66 kW @ 6000rpm
Max Torque (Nm@rpm)	113 Nm @ 4400 rpm	113 Nm @ 4400 rpm	113 Nm @ 4400 rpm	98.5 Nm @ 4300 rpm	113 Nm @ 4400 rpm	113 Nm @ 4400 rpm	98.5 Nm @ 4300 rpm	113 Nm @ 4400 rpm	113 Nm @ 4400 rpm
Number of cylinders	4	4	4	4	4	4	4	4	4

TRANSMISSION

	LXi MT	VXi MT	VXI AMT	VXI CNG MT	ZXI MT	ZXI AMT	ZXI CNG MT	ZXI+ MT	ZXI+ AMT
Types	5MT/5AMT	5MT/5AMT	5MT/5AMT	5MT	5MT/5AMT	5MT/5AMT	5MT	5MT/5AMT	5MT/5AMT

Brakes

	LXi MT	VXi MT	VXI AMT	VXI CNG MT	ZXI MT	ZXI AMT	ZXI CNG MT	ZXI+ MT	ZXI+ AMT
Front	Disc	Disc	Disc	Disc	Disc	Disc	Disc	Disc	Disc
Rear	Drum	Drum	Drum	Drum	Drum	Drum	Drum	Drum	Drum

STEERING

	LXi MT	VXi MT	VXI AMT	VXI CNG MT	ZXI MT	ZXI AMT	ZXI CNG MT	ZXI+ MT	ZXI+ AMT
Turning Radius (m)	4.8	4.8	4.8	4.8	4.8	4.8	4.8	4.8	4.8
Power Steering Type	Electric	Electric	Electric	Electric	Electric	Electric	Electric	Electric	Electric

SUSPENSION

	LXi MT	VXi MT	VXI AMT	VXI CNG MT	ZXI MT	ZXI AMT	ZXI CNG MT	ZXI+ MT	ZXI+ AMT
Front	Mac Pherson Strut	Mac Pherson Strut	Mac Pherson Strut	Mac Pherson Strut	Mac Pherson Strut	Mac Pherson Strut	Mac Pherson Strut	Mac Pherson Strut	Mac Pherson Strut
Rear	Torsion Beam	Torsion Beam	Torsion Beam	Torsion Beam	Torsion Beam	Torsion Beam	Torsion Beam	Torsion Beam	Torsion Beam

Others

	LXi MT	VXi MT	VXI AMT	VXI CNG MT	ZXI MT	ZXI AMT	ZXI CNG MT	ZXI+ MT	ZXI+ AMT
Fuel Tank Capacity (L)	37L	37L	37L	Petrol: 37L CNG: 55L (water equivalent)	37L	37L	Petrol: 37L CNG: 55L (water equivalent)	37L	37L
Kerb Weight (kg)	880-915 kg	880-915 kg	880-915 kg	990-995 kg	880-915 kg	880-915 kg	990-995 kg	880-915 kg	880-915 kg
Gross Vehicle Weight (kg)	1335 kg	1335 kg	1335 kg	1405 kg	1335 kg	1335 kg	1405 kg	1335 kg	1335 kg
Seating Capacity	5	5	5	5	5	5	5	5	5
Tyre Size (Steel)	165/80 R14	165/80 R14	165/80 R14	165/80 R14	165/80 R14	165/80 R14	165/80 R14	165/80 R14	165/80 R14
Tyre Size (Alloy)	185/65 R15	185/65 R15	185/65 R15	185/65 R15	185/65 R15	185/65 R15	185/65 R15	185/65 R15	185/65 R15

Eeco

Comfort
Instrument Panel & Console
Interior
Exterior
Safety & Security
Facilities On Board

Comfort

	5 Seater Standard	5 Seater AC	5 Seater AC CNG	7 Seater Standard	Ambulance	Ambulance Shell^*
Air Conditioner
Heater
Reclining Front Seats
Sliding Driver Seat
Head Rest-Front Row	Integrated	Integrated	Integrated	Integrated	Integrated	Integrated
Head Rest-Second Row	Fixed, Pillow	Fixed, Pillow	Fixed, Pillow	Fixed, Pillow
Head Rest-Third Row				Fixed, Pillow
Seat Back Pocket (Co-Driver Seat)
*Ambulance shell is incompletely built vehicle, for fabrication of Type B Road Ambulance, with recommended seating capacity of 3 Persons + 1 Patient.

Instrument Panel & Console

	5 Seater Standard	5 Seater AC	5 Seater AC CNG	7 Seater Standard	Ambulance	Ambulance Shell^*
Illuminated Hazard Switch
Digital Display in Instrument Cluster
12 Volt Accessory Socket
Multi Tripmeter
Digital Speedometer
Dome Lamp Battery Saver Function
*Ambulance shell is incompletely built vehicle, for fabrication of Type B Road Ambulance, with recommended seating capacity of 3 Persons + 1 Patient.

Interior

	5 Seater Standard	5 Seater AC	5 Seater AC CNG	7 Seater Standard	Ambulance	Ambulance Shell^*
Cabin Air Filter
Both Side Sunvisor
Assist Grip (Co-Driver + Rear)
Molded Roof Lining
Molded Floor Carpet
Dual Interior Color
Seat Matching Interior Color
Front Cabin Lamp
Rear Cabin Lamp
Steering Lock
*Ambulance shell is incompletely built vehicle, for fabrication of Type B Road Ambulance, with recommended seating capacity of 3 Persons + 1 Patient.

Exterior

	5 Seater Standard	5 Seater AC	5 Seater AC CNG	7 Seater Standard	Ambulance	Ambulance Shell^*
Wheel Cover	Center Cap	Center Cap	Center Cap	Center Cap	Center Cap	Center Cap
Front Mud Flaps
Outside Rear View Mirror (Left & Right)
Ambulance Decal - Front & Rear
Partly Frosted Rear side windows
Partly Frosted Back Door windows
*Ambulance shell is incompletely built vehicle, for fabrication of Type B Road Ambulance, with recommended seating capacity of 3 Persons + 1 Patient.

Safety & Security

	5 Seater Standard	5 Seater AC	5 Seater AC CNG	7 Seater Standard	Ambulance	Ambulance Shell^*
Immobilizer
Headlamp Leveling
Side Impact Beams
Child Lock for Sliding Doors & Windows
Offset Crash (as per AIS 098)^**
Seat Belts for all Seats
High Mount Stop Lamp
Reverse Parking Sensor System
Seat Belt Reminder (Dr + Co-Dr)
Speed Alert System
ABS with EBD
Dual Airbag
*Ambulance shell is incompletely built vehicle, for fabrication of Type B Road Ambulance, with recommended seating capacity of 3 Persons + 1 Patient.
**Crash Compliance is with Offset Crash (as per AIS 098).

Facilities On Board

	5 Seater Standard	5 Seater AC	5 Seater AC CNG	7 Seater Standard	Ambulance	Ambulance Shell^*
Revolving Roof Lamp
Molded Rubber Matting in Rear Cabin
Siren
Public Address System (Amplifier, Mike and Speaker)
Two LED lights inside Rear Cabin for Illuminated
Stretcher Assembly (Monoblock Stretcher)
Attendant's Seat
Space for First Aid and Nursing Kit
Oxygen Cylinder Clamp
Hook for Infusion Mounting
*Ambulance shell is incompletely built vehicle, for fabrication of Type B Road Ambulance, with recommended seating capacity of 3 Persons + 1 Patient.

Dimension & Weight
Engine (Petrol and CNG)
Transmission
Brake/Chassis

Dimension & Weight

	5 Seater Standard	5 Seater AC	5 Seater AC CNG	7 Seater Standard	Ambulance	Ambulance Shell^*
Fuel Efficiency	19.71 km/l	19.71 km/l	26.78 km/kg	19.71 km/l
Kerb Weight (kg)	935	935	1050	935	1030	940
Full Length (mm)	3675	3675	3675	3675	3675	3675
Full Width (mm)	1475	1475	1475	1475	1475	1475
Full Height (mm) Unladen	1825	1825	1825	1825	1930 (excluding top light)	1930 (excluding top light)
Seating Capacity	5	5	5	7	3+1 (Patient)	3 (with recommended seating capacity of 3 person + 1 patient after fabrication)
Tread Front (mm)	1280	1280	1280	1280	1280	1280
Tread Rear (mm)	1290	1290	1290	1290	1290	1290
Wheelbase (mm)	2350	2350	2350	2350	2350	2350
Minimum Turning Radius (m)	4.5	4.5	4.5	4.5	4.5	4.5
*Ambulance shell is incompletely built vehicle, for fabrication of Type B Road Ambulance, with recommended seating capacity of 3 Persons + 1 Patient.

Engine(Petrol and CNG)

	5 Seater Standard	5 Seater AC	5 Seater AC CNG	7 Seater Standard	Ambulance	Ambulance Shell^*
Engine Type	K12N	K12N	K12N	K12N	K12N	K12N
Engine Displacement(CC)	1197	1197	1197	1197	1197	1197
Max. Output(kw/rpm)	59.4/6000 (Gasoline)	59.4/6000 (Gasoline)	59.4/6000 (Gasoline) 52.7/6000 (CNG)	59.4/6000 (Gasoline)	59.4/6000 (Petrol)	59.4/6000 (Petrol)
Max. Torque(Nm/rpm)	104.4/3000 (Gasoline)	104.4/3000 (Gasoline)	104.4/3000 (Gasoline) 95/3000 (CNG)	104.4/3000 (Gasoline)	104.4/3000 (Petrol)	104.4/3000 (Petrol)
Tank Capacity	32 L	32 L	65 L	32 L	32 L	32 L
*Ambulance shell is incompletely built vehicle, for fabrication of Type B Road Ambulance, with recommended seating capacity of 3 Persons + 1 Patient.

Transmission

	5 Seater Standard	5 Seater AC	5 Seater AC CNG	7 Seater Standard	Ambulance	Ambulance Shell^*
Petrol & CNG	5MT	5MT	5MT	5MT	5MT	5MT
*Ambulance shell is incompletely built vehicle, for fabrication of Type B Road Ambulance, with recommended seating capacity of 3 Persons + 1 Patient.

Brake/Chassis

	5 Seater Standard	5 Seater AC	5 Seater AC CNG	7 Seater Standard	Ambulance	Ambulance Shell^*
Brake Front	Disc	Disc	Disc	Disc	Disc	Disc
Brake Rear	Drum	Drum	Drum	Drum	Drum	Drum
Front Suspension	MacPherson Strut	MacPherson Strut	MacPherson Strut	MacPherson Strut	MacPherson Strut	MacPherson Strut
Tyre Size	155R13C 8PR	155R13C 8PR	155R13C 8PR	155R13C 8PR	155R13C 8PR	155R13C 8PR
*Ambulance shell is incompletely built vehicle, for fabrication of Type B Road Ambulance, with recommended seating capacity of 3 Persons + 1 Patient.

Ertiga

INFOTAINMENT SYSTEM
COMFORT & CONVENIENCE
EXTERIOR
INSTRUMENT CLUSTER
INTERIOR
SAFETY AND SECURITY
**SUZUKI CONNECT

INFOTAINMENT SYSTEM

	Zxi MT	ZXi AT	ZXi CNG	ZXi+ MT	ZXi+ AT
17.78cm SmartPlay Pro Touch Screen Infotainment System
17.78cm SmartPlay Studio Touch Screen Infotainment System
Premium Sound System				ARKAMYS (Surround Sense)	ARKAMYS (Surround Sense)
Android Auto^* & Apple Can Play^~				Wireless	Wireless
Audio System with Electrostatic Touch Buttons
Bluetooth Connectivity
Speakers(4)
Tweeters(2)
USB and AUX Connectivity	USB Only	USB Only	USB Only	USB Only	USB Only
Steering Mounted Audio Control
Steering Mounted Calling Control
^* Android Auto™ extends the Android platform into the car in a way that's purpose-built for driving. It is designed to minimise distraction so you can focus on driving with Google™ services like Google Maps™ and Google Search™. Get the Android Auto app on Google Play™. Android Auto is available in the countries listed at the following link:https://www.android.com/auto/#hit-the-road. Most phones with Android 5.0+ work with Android Auto: https://support.google.com/androidauto/#6140477. Android, Android Auto, Google, Google Play and other marks are trademarks of Google Inc. Image used are for illustration purposes only.
^~ Apple and iPhone are trademarks of Apple Inc. registered in the U.S. and other countries. Apple CarPlay is a trademark of Apple Inc., Apple CarPlay is available in the countries listed in the following link: http://www.apple.com/ios/feature-availability/#applecarplay-applecarplay. Apple CarPlay is compatible with the iPhone models listed in the following link:http://www/apple.com/ios/carplay

COMFORT & CONVENIENCE

	VXi MT	VXi AT	VXi CNG	Zxi MT	ZXi AT	ZXi CNG	ZXi+ MT	ZXi+ AT
Engine Push Start/Stop with Smart Key
Manual AC (Front)
Auto AC (Front)
2nd Row Roof Mounted AC with 3 Stage Speed Control
Air Cooled Twin Cup Holders (Console)
Rear Defogger
Remote Keyless Entry				(Smart Key)	(Smart Key)	(Smart Key)	(Smart Key)	(Smart Key)
Power Socket (12V) Front Row with Smartphone Storage Space
Power Socket (12V) 2nd Row
2nd Row Smart Phone Storage Space
Power Socket (12V) 3rd Row
Power Windows (Fr/Rr) with Dr. Side Auto Down Functions
Auto Window Up (Dr. Side with anti-pinch)
Day & Night Adjustable IRVM
Power & Tilt Steering
Electrically Adjustable ORVMs
Electrically Foldable ORVMs
Retractable ORVMs (Key Operated)
Bottle Holders (in each row)
Coin/Ticket Holder (Driver Side)
Cabin Lamp (Fr.+Rr.)
Cruise Control
Paddle Shifters	(AT)	(AT)	(AT)	(AT)	(AT)	(AT)	(AT)	(AT)
Foot Rest
Auto Headlamps with Follow Me Home/Lead me to Vehicle Feature

EXTERIOR

	LXi MT	VXi MT	VXi AT	VXi CNG	Zxi MT	ZXi AT	ZXi CNG	ZXi+ MT	ZXi+ AT
Projector Headlamps (Halogen)
3D Origami Style LED Tail Lamps
Dynamic Chrome Winged Front Grille	Painted	Chrome	Chrome	Chrome	Chrome	Chrome	Chrome	Chrome	Chrome
Floating Type Roof Design in Rear
Full Wheel Caps
Machined Two-tone Alloy Wheels
Turn Signal Lamp Integrated in ORVMs
New Back Door Garnish with Chrome Insert
Rear Wiper & Washer
Body Coloured Door Handles
Chrome Plated Door Handles
Body Coloured ORVMs

INSTRUMENT CLUSTER

	VXi MT	VXi AT	VXi CNG	Zxi MT	ZXi AT	ZXi CNG
MID With Coloured TFT
Tachometer
Gear Shift Indicator (MT)
Digital Clock
Outside Temperature Gauge
Fuel Consumption (Instantaneous and Avg)^##
Dedicated CNG Fuel Gauge	(CNG)	(CNG)	(CNG)	(CNG)	(CNG)	(CNG)
Total CNG Mode Time	(CNG)	(CNG)	(CNG)	(CNG)	(CNG)	(CNG)
Distance to Empty^##
Headlamp On Warning
Door Ajar Warning Lamp
^##Except CNG.

INTERIORS

	VXi MT	VXi AT	VXi CNG	Zxi MT	ZXi AT	ZXi CNG
Sculpted Dashboard with Metallic Teak - Wooden Finish
Metallic Teak-Wooden Finish on Door Trims (Fr.)
Premium Dual Tone Interiors
Height Adjustable Driver Seat
2nd Row 60:40 Split Seats with One Touch Recline & Slide
3rd Row 50:50 Split Seats with Recline function
Flexible luggage space with Flat Fold (3rd Row)
Plush Dual-Tone Seat Fabric
Fr. Seat Back Pockets	Co-driver	Co-driver	Co-driver
Sliding Armrest with Utility Box (Front Row)
2nd Row Center Armrest
Leather Wrapped Steering Wheel with Metallic Teak-Wooden Finish
Adjustable Headrest (All Rows)
Split Type Luggage Board	(Expect CNG)	(Expect CNG)	(Expect CNG)	(Expect CNG)	(Expect CNG)	(Expect CNG)
Driver Side Sunvisor with Ticket Holder
Passenger Side Sunvisor with Vanity Mirror
Dazzle Chrome Tipped Parking Brake Lever
Gear Shift Knob with Dazzle Chrome Finish

SAFETY AND SECURITY

	LXi MT	VXi MT	VXi AT	VXi CNG	Zxi MT	ZXi AT	ZXi CNG	ZXi+ MT	ZXi+ AT
Suzuki Heartect Platform
Dual Front Airbags
Fr.Seat Side Airbags
ABS with EBD and Brake Assist
Engine Immobilizer
ESP
Hill Hold
ISOFIX Child Seat Anchorages (2nd Row Seats)
Front Seat Belts with Pre-tensioner & Force Limiters (Dr.+Co-Dr.)
Seat Belt Reminder Lamp and Buzzer (All Passengers)^{^^^}
Front Seat Belt Height Adjuster
High Speed Alert System^{^}
Speed Sensitive Auto Door Lock
Security Alarm
Rear Parking Sensors
Rear Parking Camera
Central Locking
Front Fog Lamps
^{^^^} Seatbelt reminder comes on unless all rear passengers' seat belts are fastened irrespective of the presence or absence of passenger. Seat belt reminder lamp will continue to glow in the instrument cluster till seat belt is buckled, whereas buzzer will beep for approximately 95 secs or till the passenger buckles the seatbelt (whichever is the earliest.)
^{^} The speed alert system gives audible warning for alert of over-speed to driver. When vehicle speed exceeds about 80 km/h, primary level warning with two beeps will sound every minute. When the vehicle speed exceeds about 120 km/h, secondary level warning with continuous beeps will sound. If the vehicle speed is slowed down to about 118 km/h, primary warning will resume. If the vehicle is slowed down to about 78 km/h, speed alert warning will stop. This buzzer does not indicate any malfunction in vehicle.

**SUZUKI CONNECT

	Zxi MT	ZXi AT	ZXi CNG	ZXi+ MT	ZXi+ AT
Safety and Security
Emergency Alerts
Breakdown notification
Stolen Vehicle Notification and Tracking
Tow Away Alert and Tracking
Geo-Fence
Time Fence
Valet Alert
Trips and Driving Behaviour
Trip Summary
Driving Behaviour
Share Trip History
Area Guidance Around Destination
Vehicle location Sharing
Alerts and Notification
Overspeed
Seatbelt
AC Idling
Trip (Start &End)
Low Fuel & Low Range^##
Dashboard View
Remote functions
Door Lock/Cancel Lock
Hazard Light ON/OFF
Headlight OFF
Alarm
Immobilizer Request
Battery Health
Smartwatch Connectivity
Suzuki Connect skill for Amazon, Alexa****
Remote Ac	(AT)	(AT)	(AT)	(AT)	(AT)
^Suzuki Connect (available through phone/smartwatch/Suzuki connect skill for Amazon Alexa).**
^##Except CNG.
****Amazon, Alexa and all related marks are trademarks of Amazon.com, Inc. or its affiliates. This is to clarify that LXi (O), VXi (O) & ZXi (O) are same variants with same features as LXi , VXi & ZXi.

Dimensions
Engine
Drive & Transmission
Brake
Suspension
New Technology
Weight

Dimension

	LXi MT	VXi MT	VXi AT	VXi MT CNG	Zxi MT	ZXi AT	ZXi MT CNG	ZXi+ MT	ZXi+ AT
Length (mm)	4395	4395	4395	4395	4395	4395	4395	4395	4395
Width (mm)	1735	1735	1735	1735	1735	1735	1735	1735	1735
Height (mm)(Unladen)	1690	1690	1690	1690	1690	1690	1690	1690	1690
Wheelbase (mm)	2740	2740	2740	2740	2740	2740	2740	2740	2740
Turning Radius (m)	5.2	5.2	5.2	5.2	5.2	5.2	5.2	5.2	5.2
Seating Capacity	7	7	7	7	7	7	7	7	7

Engine

	LXi MT	VXi MT	VXi AT	VXi MT CNG	Zxi MT	ZXi AT	ZXi MT CNG	ZXi+ MT	ZXi+ AT
Type	K15C SMART HYBRID	K15C SMART HYBRID	K15C SMART HYBRID	K15C	K15C SMART HYBRID	K15C SMART HYBRID	K15C	K15C SMART HYBRID	K15C SMART HYBRID
Capacity (cc)	1462	1462	1462	1462	1462	1462	1462	1462	1462
Compression Ratio	12 ± 0.3	12 ± 0.3	12 ± 0.3	12 ± 0.3	12 ± 0.3	12 ± 0.3	12 ± 0.3	12 ± 0.3	12 ± 0.3
Power (KW@RPM)	75.8@6000	75.8@6000	75.8@6000	74.0 @ 6000 (Gasoline Mode) 64.6 @ 5500 (CNG Mode)	75.8@6000	75.8@6000	74.0 @ 6000 (Gasoline Mode) 64.6 @ 5500 (CNG Mode)	75.8@6000	75.8@6000
Torque(Nm@RPM)	136.8@4400	136.8@4400	136.8@4400	136.0 @ 4400 (Gasoline Mode) 121.5 @ 4200 (CNG Mode)	136.8@4400	136.8@4400	136.0 @ 4400 (Gasoline Mode) 121.5 @ 4200 (CNG Mode)	136.8@4400	136.8@4400
Emission Type	BS VI	BS VI	BS VI	BS VI	BS VI	BS VI	BS VI	BS VI	BS VI
Fuel Tank Capacity (L)	45	45	45	Petrol:45 CNG: 60 (Water Equivalent)	45	45	Petrol:45 CNG: 60 (Water Equivalent)	45	45

Drive & Transmission

	LXi MT	VXi MT	VXi AT	VXi MT CNG	Zxi MT	ZXi AT	ZXi MT CNG	ZXi+ MT	ZXi+ AT
Drive	2WD,FF	2WD,FF	2WD,FF	2WD,FF	2WD,FF	2WD,FF	2WD,FF	2WD,FF	2WD,FF
Transmission	5MT/6AT	5MT/6AT	5MT/6AT	5MT	5MT/6AT	5MT/6AT	5MT	5MT/6AT	5MT/6AT

Break

	LXi MT	VXi MT	VXi AT	VXi MT CNG	Zxi MT	ZXi AT	ZXi MT CNG	ZXi+ MT	ZXi+ AT
Front	Disc	Disc	Disc	Disc	Disc	Disc	Disc	Disc	Disc
Rear	Drum	Drum	Drum	Drum	Drum	Drum	Drum	Drum	Drum

Suspension

	LXi MT	VXi MT	VXi AT	VXi MT CNG	Zxi MT	ZXi AT	ZXi MT CNG	ZXi+ MT	ZXi+ AT
Front	Mac Pherson Strut & Coil Spring	Mac Pherson Strut & Coil Spring	Mac Pherson Strut & Coil Spring	Mac Pherson Strut & Coil Spring	Mac Pherson Strut & Coil Spring	Mac Pherson Strut & Coil Spring	Mac Pherson Strut & Coil Spring	Mac Pherson Strut & Coil Spring	Mac Pherson Strut & Coil Spring
Rear	Torsion Beam & Coil Spring	Torsion Beam & Coil Spring	Torsion Beam & Coil Spring	Torsion Beam & Coil Spring	Torsion Beam & Coil Spring	Torsion Beam & Coil Spring	Torsion Beam & Coil Spring	Torsion Beam & Coil Spring	Torsion Beam & Coil Spring
Tyre Size	185/65 R15	185/65 R15	185/65 R15	185/65 R15	185/65 R15	185/65 R15	185/65 R15	185/65 R15	185/65 R15

New Technology

	LXi MT	VXi MT	VXi AT	VXi MT CNG	Zxi MT	ZXi AT	ZXi MT CNG	ZXi+ MT	ZXi+ AT
Idle Start Stop
Brake Energy Regeneration
Torque Assist

Weight

	LXi MT	VXi MT	VXi AT	VXi MT CNG	Zxi MT	ZXi AT	ZXi MT CNG	ZXi+ MT	ZXi+ AT
Kerb Weight (kg)	1150-1205	1150-1205	1150-1205	1250-1255	1150-1205	1150-1205	1250-1255	1150-1205	1150-1205
Gross Vehicle Weight (kg)	1760(MT),1785(AT)	1760(MT),1785(AT)	1760(MT),1785(AT)	1820	1760(MT),1785(AT)	1760(MT),1785(AT)	1820	1760(MT),1785(AT)	1760(MT),1785(AT)

Swift

Exteriors
Interiors
Safety & Security
Audio & Entertainment
Comfort & Convenience
Colour Variants

Exteriors

	Lxi 5MT	Vxi 5MT	Vxi 5AMT	Zxi 5MT	Zxi 5AMT	Zxi+ 5MT	Zxi+ 5AMT	Vxi CNG 5MT	Zxi CNG 5MT
LED Projector Headlamps
LED Daylight Running Lamps
LED Rear Combination Lamp
LED High Mounted Stop Lamp
Wheels (Steel/Alloy/Precision Cut Alloy)	Steel	Steel	Steel	Alloy	Alloy	Precision Cut Alloy	Precision Cut Alloy	Steel	Alloy
Full Wheel Covers
Side Turn Indicators on ORVMs
Body Coloured ORVMs						(Roof Colour in Dual Tone)	(Roof Colour in Dual Tone)
Body Coloured Bumpers
Body Coloured Outside Front Door Handles

Interiors

	Vxi 5MT	Vxi 5AMT	Zxi+ 5MT	Zxi+ 5AMT
Leather^ Wrapped Steering Wheel
Silver Ornament on Front Door Armrest
Outside Temperature Display	(AMT only)	(AMT only)
Co-Driver Side Sunvisor with Vanity Mirror
Driver Side Sunvisor with Ticket Holder
Front Seat Back Pocket (Co-Driver side)
Chrome Parking Brake Lever Tip
IP Ornament
Gear Shift Knob in Piano Black Finish
Chrome Inside Door Handles
Tachometer
Front Dome Lamp
Multi-Information Display			(Coloured)	(Coloured)
^Certain parts of the leather upholstery contain man-made material.

Safety & Security

	Vxi 5MT	Vxi 5AMT	Zxi 5MT	Zxi 5AMT	Zxi+ 5MT	Zxi+ 5AMT
Dual Front Airbags##
ABS with EBD and Brake Assist
ESP with Hill Hold Assist	(AMT only)	(AMT only)	(AMT only)	(AMT only)	(AMT only)	(AMT only)
Reverse Parking Sensors
Reverse Parking Camera
Security Alarm System
Pinch Guard Power Window (Driver Side)
Front Seat Belts with Pre-Tensioner and Force Limiter
Pedestrian Protection Compliance
IsoFix with Child Seat Anchorages
Front Fog Lamps
Speed Sensitive Automatic Door Lock
Seat Belt Reminder & Buzzer (Driver & Co-Driver Side)
Day and Night Adjustable IRVM
Engine Immobilizer
High Speed Alert System*
##For details on functioning of safety features, including air bag, kindly refer to the Owner's Manual.
*The speed alert system gives audible warning for alert of over-speed to driver. When vehicle speed exceeds about 80 km/h, primary level warning with two beeps will sound every minute. When the vehicle speed exceeds about 120 km/h, secondary level warning with continuous beeps will sound. If the vehicle speed is slowed down to about 118 km/h, primary warning will resume. If the vehicle is slowed down to about 78 km/h, speed alert warning will stop. This buzzer does not indicate any malfunction in vehicle.

Audio & Entertainment

	Lxi 5MT	Vxi 5MT	Vxi 5AMT	Zxi 5MT	Zxi 5AMT	Zxi+ 5MT	Zxi+ 5AMT	Vxi CNG 5MT	Zxi CNG 5MT
17.78 cm Touchscreen Smartplay Studio
Navigation System with Live Traffic Update(through Smartplay Studio App)
AHA Platform (through Smartplay Studio App)
Voice Command
Smartphone Connect (Android Auto and Apple CarPlay)
Remote Control (through Smartplay Studio App)
All New Feather Touch Audio System
Steering Mounted Audio & Calling Controls
AUX-in, USB & Bluetooth Connectivity
Door Speakers (4)
Tweeters (2)
Roof Antenna

Comfort & Convenience

	Vxi 5MT	Vxi 5AMT	Zxi 5MT	Zxi 5AMT	Zxi+ 5MT	Zxi+ 5AMT
Cruise Control
Engine Push Start-Stop Button with Smart Key
Auto Headlamps(lead me to vehicle/follow me home)
Automatic Climate Control
Manual Air Conditioner with Heater
Remote Keyless Entry System
Central Door Locking
Auto Down Power Window (Driver Side)
Auto Up Power Window (Driver Side)
Power Windows (Front + Rear)
Power & Tilt Steering
Manually Adjustable ORVMs
Electrically Adjustable ORVMs
Electrically Foldable ORVMs					(Key Sync)	(Key Sync)
Electromagnetic Back Door Opener
Rear Defogger
Rear Wiper & Washer
Adjustable Front Seat Headrests
Adjustable Rear Seat Headrests
Height Adjustable Driver Seat
Gear Shift Indicator	(MT only)	(MT only)	(MT only)	(MT only)	(MT only)	(MT only)
Gear Position Indicator	(AMT only)	(AMT only)	(AMT only)	(AMT only)	(AMT only)	(AMT only)
Driver Side Foot Rest	(AMT only)	(AMT only)	(AMT only)	(AMT only)	(AMT only)	(AMT only)
60:40 Split Rear Seat
Rear Parcel Shelf
Luggage Room Lamp
Front Accessory Socket
Low Fuel Warning Lamp
Door Ajar Warning Lamp
Headlamp On Reminder

Colour Variants

	Lxi 5MT	Vxi 5MT	Vxi 5AMT	Zxi 5MT	Zxi 5AMT	Zxi+ 5MT	Zxi+ 5AMT	Vxi CNG 5MT	Zxi CNG 5MT
Solid Fire Red with Pearl Midnight Black Roof
Pearl Metallic Midnight Blue with Pearl Arctic White Roof
Pearl Arctic White with Pearl Midnight Black Roof
Solid Fire Red
Pearl Metallic Midnight Blue
Pearl Arctic White
Pearl Metallic Lucent Orange
Metallic Magma Grey
Metallic Silky Silver

Seating Capacity
Engine
Transmission
Dimensions
Weight
Brakes
Steering
Suspension
Tyre Size
Fuel Tank

Seating Capacity

	Lxi 5MT	Vxi 5MT	Vxi 5AMT	Zxi 5MT	Zxi 5AMT	Zxi+ 5MT	Zxi+ 5AMT	Vxi CNG 5MT	Zxi CNG 5MT
Capacity	5	5	5	5	5	5	5	5	5

Engine

	Lxi 5MT	Vxi 5MT	Vxi 5AMT	Zxi 5MT	Zxi 5AMT	Zxi+ 5MT	Zxi+ 5AMT	Vxi CNG 5MT	Zxi CNG 5MT
Engine Type	Advanced K Series Dual Jet, Dual VVT Engine	Advanced K Series Dual Jet, Dual VVT Engine	Advanced K Series Dual Jet, Dual VVT Engine	Advanced K Series Dual Jet, Dual VVT Engine	Advanced K Series Dual Jet, Dual VVT Engine	Advanced K Series Dual Jet, Dual VVT Engine	Advanced K Series Dual Jet, Dual VVT Engine	Advanced K Series Dual Jet, Dual VVT Engine	Advanced K Series Dual Jet, Dual VVT Engine
Fuel Type	Gasoline	Gasoline	Gasoline	Gasoline	Gasoline	Gasoline	Gasoline	Gasoline & CNG	Gasoline & CNG
Emission Type	BS VI	BS VI	BS VI	BS VI	BS VI	BS VI	BS VI	BS VI	BS VI
Capacity	1197cc	1197cc	1197cc	1197cc	1197cc	1197cc	1197cc	1197cc	1197cc
Number of Cylinders	4	4	4	4	4	4	4	4	4
Max Power (kW @ rpm)(PS@rpm)	66 kW @ 6000 rpm 89.73 PS @6000 rpm	66 kW @ 6000 rpm 89.73 PS @6000 rpm	66 kW @ 6000 rpm 89.73 PS @6000 rpm	66 kW @ 6000 rpm 89.73 PS @6000 rpm	66 kW @ 6000 rpm 89.73 PS @6000 rpm	66 kW @ 6000 rpm 89.73 PS @6000 rpm	66 kW @ 6000 rpm 89.73 PS @6000 rpm	57 kW @ 6000 rpm 77.49 PS @6000 rpm	57 kW @ 6000 rpm 77.49 PS @6000 rpm
Max Torque (Nm @ rpm)	113@4400	113@4400	113@4400	113@4400	113@4400	113@4400	113@4400	98.5@4300	98.5@4300

Transmission

	Lxi 5MT	Vxi 5MT	Vxi 5AMT	Zxi 5MT	Zxi 5AMT	Zxi+ 5MT	Zxi+ 5AMT	Vxi CNG 5MT	Zxi CNG 5MT
Type	5MT/5AMT	5MT/5AMT	5MT/5AMT	5MT/5AMT	5MT/5AMT	5MT/5AMT	5MT/5AMT	5MT	5MT

Dismensions

	Lxi 5MT	Vxi 5MT	Vxi 5AMT	Zxi 5MT	Zxi 5AMT	Zxi+ 5MT	Zxi+ 5AMT	Vxi CNG 5MT	Zxi CNG 5MT
Length (mm)	3845	3845	3845	3845	3845	3845	3845	3845	3845
Width (mm)	1735	1735	1735	1735	1735	1735	1735	1735	1735
Height (mm)	1530 (Unladen)	1530 (Unladen)	1530 (Unladen)	1530 (Unladen)	1530 (Unladen)	1530 (Unladen)	1530 (Unladen)	1530 (Unladen)	1530 (Unladen)
Wheelbase (mm)	2450	2450	2450	2450	2450	2450	2450	2450	2450
Track, Front (mm)	1530(165/80R14), 1520(185/65R15)	1530(165/80R14), 1520(185/65R15)	1530(165/80R14), 1520(185/65R15)	1530(165/80R14), 1520(185/65R15)	1530(165/80R14), 1520(185/65R15)	1530(165/80R14), 1520(185/65R15)	1530(165/80R14), 1520(185/65R15)	1530(165/80R14), 1520(185/65R15)	1530(165/80R14), 1520(185/65R15)
Track, Rear (mm)	1530(165/80R14), 1520(185/65R15)	1530(165/80R14), 1520(185/65R15)	1530(165/80R14), 1520(185/65R15)	1530(165/80R14), 1520(185/65R15)	1530(165/80R14), 1520(185/65R15)	1530(165/80R14), 1520(185/65R15)	1530(165/80R14), 1520(185/65R15)	1530(165/80R14), 1520(185/65R15)	1530(165/80R14), 1520(185/65R15)
Boot Space (L)	268	268	268	268	268	268	268

Weight

	Lxi 5MT	Vxi 5MT	Vxi 5AMT	Zxi 5MT	Zxi 5AMT	Zxi+ 5MT	Zxi+ 5AMT	Vxi CNG 5MT	Zxi CNG 5MT
Kerb Weight (Kg)	875-905	875-905	875-905	875-905	875-905	875-905	875-905	980-985	980-985
Gross Vehicle Weight (Kg)	1335	1335	1335	1335	1335	1335	1335	1405	1405

Brakes

	Lxi 5MT	Vxi 5MT	Vxi 5AMT	Zxi 5MT	Zxi 5AMT	Zxi+ 5MT	Zxi+ 5AMT	Vxi CNG 5MT	Zxi CNG 5MT
Front	Disc	Disc	Disc	Disc	Disc	Disc	Disc	Disc	Disc
Rear	Drum	Drum	Drum	Drum	Drum	Drum	Drum	Drum	Drum

Steering

	Lxi 5MT	Vxi 5MT	Vxi 5AMT	Zxi 5MT	Zxi 5AMT	Zxi+ 5MT	Zxi+ 5AMT	Vxi CNG 5MT	Zxi CNG 5MT
Power Steering Type	Electric	Electric	Electric	Electric	Electric	Electric	Electric	Electric	Electric
Turning Radius(m)	4.8	4.8	4.8	4.8	4.8	4.8	4.8	4.8	4.8

Suspension

	Lxi 5MT	Vxi 5MT	Vxi 5AMT	Zxi 5MT	Zxi 5AMT	Zxi+ 5MT	Zxi+ 5AMT	Vxi CNG 5MT	Zxi CNG 5MT
Front	Mac Pherson Strut	Mac Pherson Strut	Mac Pherson Strut	Mac Pherson Strut	Mac Pherson Strut	Mac Pherson Strut	Mac Pherson Strut	Mac Pherson Strut	Mac Pherson Strut
Rear	Torsion Beam	Torsion Beam	Torsion Beam	Torsion Beam	Torsion Beam	Torsion Beam	Torsion Beam	Torsion Beam	Torsion Beam

Tyre Size

	Lxi 5MT	Vxi 5MT	Vxi 5AMT	Zxi 5MT	Zxi 5AMT	Zxi+ 5MT	Zxi+ 5AMT	Vxi CNG 5MT	Zxi CNG 5MT
Steel	165/80 R14	165/80 R14	165/80 R14					Vxi : 165/80 R14
Alloy**				185/65 R15	185/65 R15	185/65 R15	185/65 R15		Zxi: 185/65 R15
**Spare wheel material is steel and spare tyre size is 165/80R14.

Feul Tank

	Lxi 5MT	Vxi 5MT	Vxi 5AMT	Zxi 5MT	Zxi 5AMT	Zxi+ 5MT	Zxi+ 5AMT	Vxi CNG 5MT	Zxi CNG 5MT
Fuel Tank Capacity (L)	37	37	37	37	37	37	37	Gasoline: 37 L CNG: 55 L(water filling capacity)	Gasoline: 37 L CNG: 55 L(water filling capacity)

S-Presso

Interiors
Comfort
Infotainment System
Safety and Security
Exterior
Instrument Cluster

Interiors

	VXi+ MT	VXi+(O) AGS
Dynamic Centre Console
High Seating for commanding drive view
Coloured Centre Garnish	**	**
Front Cabin Lamp (3 positions)
Sunvisor (Dr+Co. Dr)
**Orange in solid sizzle orange body colour & Silver in the remaining 5 body colours.

Comfort

	LXi MT	LXi CNG MT	VXi MT	VXi(O) AGS	VXi CNG MT
AC with Heater
Power Steering
Accessory Socket
Front Console Utility Space
1L Bottle Holders with Map Pockets (Front doors)
Rear Console Utility Space
Co-Driver Side Utility Space
Reclining & Front Sliding Seats
Remote keyless entry
Rear Parcel Tray
Front Power Windows
Internally Adjustable ORVMs (Dr+Co. Dr)
Electrically Adjustable ORVMs (Dr+Co. Dr)
Idle Start Stop (ISS)	Petrol Variant Only	Petrol Variant Only	Petrol Variant Only	Petrol Variant Only	Petrol Variant Only

Infotainment System

	VXi MT	VXi(O) AGS	VXi CNG MT	VXi+ MT	VXi+(O) AGS
SmartPlay Studio - 17.78 cm Touch screen Infotainment System
SmartPlay Dock
Apple Car Play and Android Auto^###
Bluetooth
Speakers	2	2	2	2	2
USB connectivity/Aux
Steering-Mounted Audio & Voice Control
HEARTECT Platform
###Apple and iPhone are trademarks of Apple Inc. registered in the U.S. and other countries. Apple CarPlay is a trademark of Apple Inc., Apple CarPlay is available in the countries listed in the following link: http://www.apple.com/ios/feature-availability/#applecarplay-applecarplay. Apple CarPlay is compatible with the iPhone models listed in the following link: http://www/apple.com/ios/carplay. Android Auto™ extends the Android platform into the car in a way that's purpose-built for driving. It is designed to minimise distraction so you can focus on driving with Google™ services like Google Map™ and Google Search™. Get the Android Auto app on Google Play™. Android Auto is available in the countries listed at the following link: https://www.android.com/auto/#hit-the-road. Most phones with Android 5.0+ work with Android Auto: https://support.google.com/androidauto/#6140477. Android, Android Auto, Google, Google Play and other marks are trademarks of Google Inc.

Safety and Security

	Std MT	LXi MT	LXi CNG MT	VXi MT	VXi(O) AGS	VXi CNG MT	VXi+ MT	VXi+(O) AGS
Cabin Air Filter
ESP with Hill Hold				AGS Only	AGS Only	AGS Only	AGS Only	AGS Only
ABS with EBD
Seat Belt Reminder with Buzzer Front + Rear seat^{^^}
Rear Seat Belt Center (2-Point Static)		Petrol variant only	Petrol variant only	Petrol variant only	Petrol variant only	Petrol variant only
Rear Seat Belt Outboard (3-Point)	(Static)	(Static)	(Static)	(ELR)	(ELR)	(ELR)	(ELR)	(ELR)
Reverse Parking Sensors
Speed Alert System^{^}
Pedestrian Protection
Child Proof Rear Door Lock
Speed Sensitive Auto Door Lock
Central Door Locking
Dual Airbag^#
Front Seatbelt Pre-tensioner and Force Limiter
Low Fuel Warning (Petrol Fuel)				SmartPlay Dock	SmartPlay Dock	SmartPlay Dock	SmartPlay Studio	SmartPlay Studio
Door Ajar Warning				SmartPlay Dock	SmartPlay Dock	SmartPlay Dock	SmartPlay Studio	SmartPlay Studio
Parking Brake Warning
^^Seat belt reminder comes on unless all rear passenger's seat belts are fastened irrespective of the presence or absence of passenger.
^The speed alert system gives audible warning for alert of over-speed to driver. When the vehicle speed exceeds about 80km/h, primary level warning with two beeps will sound every minute. When the vehicle speed exceeds about 120km/h, secondary level warning with continuous beeps will sound. If the vehicle speed is slowed down to about 118km/h, primary warning will resume. If the vehicle is slowed down to 78km/h, speed alert warning will stop. This buzzer does not indicate any malfunction in vehicle.
#For details on the functioning of safety features including airbags, kindly refer to the Owners Manual.

Exterior

	Std MT	LXi MT	LXi CNG MT	VXi MT	VXi(O) AGS	VXi CNG MT	VXi+ MT	VXi+(O) AGS
SUV Inspired Bold Front Fascia
Twin Chamber Headlamps
Roof Antenna
Signature C shaped Tail Lamps
B-Pillar Black Out Tape
Side Body Cladding
Body Coloured Bumpers
Body Coloured ORVMs
Body Coloured Outside Door Handles
Full Wheel Covers

Instrument Cluster

	VXi MT	VXi(O) AGS	VXi CNG MT	VXi+ MT	VXi+(O) AGS
Digital Display in the Instrument Cluster
Fuel Consumption (Instantaneous & Average)
Headlamp On Warning
Gear Shift Indicator (MT Only)	Petrol Variant Only	Petrol Variant Only	Petrol Variant Only
Gear Position Indicator	AGS Only	AGS Only	AGS Only	AGS Only	AGS Only
Distance to empty

Dimensions
Engine
Emission Type
Drive & Transmission
Brake
Suspension
Weight

Dimensions

	Std MT	LXi MT	LXi CNG MT	VXi MT	VXi(O) AGS	VXi CNG MT	VXi+ MT	VXi+(O) AGS
Length (mm)	3565	3565	3565	3565	3565	3565	3565	3565
Width (mm)	1520	1520	1520	1520	1520	1520	1520	1520
Height (mm)	1553	1553	1553	1567	1567	1567	1567	1567
Wheelbase (mm)	2380	2380	2380	2380	2380	2380	2380	2380
Turning Radius (m)	4.5	4.5	4.5	4.5	4.5	4.5	4.5	4.5
Seating Capacity	5	5	4	5	5	4	5	5

Engine

	Std MT	LXi MT	LXi CNG MT	VXi MT	VXi(O) AGS	VXi CNG MT	VXi+ MT	VXi+(O) AGS
Type	K10C	K10C	K1OC CNG	K10C	K10C	K1OC CNG	K10C	K10C
Capacity (cc)	998	998	998	998	998	998	998	998
Power	49 kW(66.621PS) @ 5500 rpm	49 kW(66.621PS) @ 5500 rpm	41.7 kW (56.696PS) @ 5300 rpm (CNG Mode) 48 kW (65.261PS) @ 5500 rpm (Petrol Mode)	49 kW(66.621PS) @ 5500 rpm	49 kW(66.621PS) @ 5500 rpm	41.7 kW (56.696PS) @ 5300 rpm (CNG Mode) 48 kW (65.261PS) @ 5500 rpm (Petrol Mode)	49 kW(66.621PS) @ 5500 rpm	49 kW(66.621PS) @ 5500 rpm
Torque	89 Nm @ 3500 rpm	89 Nm @ 3500 rpm	82.1 Nm @ 3400 rpm (CNG Mode) 89 Nm @ 3500 rpm (Petrol Mode)	89 Nm @ 3500 rpm	89 Nm @ 3500 rpm	82.1 Nm @ 3400 rpm (CNG Mode) 89 Nm @ 3500 rpm (Petrol Mode)	89 Nm @ 3500 rpm	89 Nm @ 3500 rpm
Fuel Type	Petrol	Petrol	Petrol+CNG	Petrol	Petrol	Petrol+CNG	Petrol	Petrol
Fuel Tank Capacity (L)	27	27	27 (Petrol Mode) 55 (CNG Mode) (Equivalent Water Filling Capacity)	27	27	27 (Petrol Mode) 55 (CNG Mode) (Equivalent Water Filling Capacity)	27	27

Emission Type

	Std MT	LXi MT	LXi CNG MT	VXi MT	VXi(O) AGS	VXi CNG MT	VXi+ MT	VXi+(O) AGS
Type	BS VI	BS VI	BS VI	BS VI	BS VI	BS VI	BS VI	BS VI

Drive & Transmission

	Std MT	LXi MT	LXi CNG MT	VXi MT	VXi(O) AGS	VXi CNG MT	VXi+ MT	VXi+(O) AGS
Drive	2WD, FF	2WD, FF	2WD, FF	2WD, FF	2WD, FF	2WD, FF	2WD, FF	2WD, FF
Transmission	5MT/ AGS	5MT/ AGS	5MT	5MT/ AGS	5MT/ AGS	5MT	5MT/ AGS	5MT/ AGS

Brake

	Std MT	LXi MT	LXi CNG MT	VXi MT	VXi(O) AGS	VXi CNG MT	VXi+ MT	VXi+(O) AGS
Front	Ventilated Disc	Ventilated Disc	Ventilated Disc	Ventilated Disc	Ventilated Disc	Ventilated Disc	Ventilated Disc	Ventilated Disc
Rear	Drum	Drum	Drum	Drum	Drum	Drum	Drum	Drum

Suspension

	Std MT	LXi MT	LXi CNG MT	VXi MT	VXi(O) AGS	VXi CNG MT	VXi+ MT	VXi+(O) AGS
Front	MacPherson Strut with Coil Spring	MacPherson Strut with Coil Spring	Mac Pherson Strut with Coil Spring and Stabilizer Bar	MacPherson Strut with Coil Spring	MacPherson Strut with Coil Spring	Mac Pherson Strut with Coil Spring and Stabilizer Bar	MacPherson Strut with Coil Spring	MacPherson Strut with Coil Spring
Rear	Torsion Beam with Coil Spring	Torsion Beam with Coil Spring	Torsion Beam with Coil Spring	Torsion Beam with Coil Spring	Torsion Beam with Coil Spring	Torsion Beam with Coil Spring	Torsion Beam with Coil Spring	Torsion Beam with Coil Spring
Tyre Size	145/80 R13	145/80 R13	145/80 R13	165/70 R14	165/70 R14	165/70 R14	165/70 R14	165/70 R14

Weight

	Std MT	LXi MT	LXi CNG MT	VXi MT	VXi(O) AGS	VXi CNG MT	VXi+ MT	VXi+(O) AGS
Kerb Weight (kg)	736-775	736-775	834-854	736-775	736-775	834-854	736-775	736-775
Maximum GVW (kg)	1170	1170	1170	1170	1170	1170	1170	1170

Brezza

Exteriors
Interiors
Safety
INFOTAINMENT
Comfort & Convenience
Colour Variants

Exteriors

	LXI MT	LXI CNG MT	VXI MT	VXI AT	VXI CNG MT	ZXI MT	ZXI AT	ZXI CNG MT	ZXI+ MT	ZXI+ AT
Auto Headlamps with Follow me Home & Lead Me to Vehicle
Alloy Wheels						(Painted)	(Painted)	(Painted)	(Precision Cut)	(Precision Cut)
Steel Wheels with Wheel cover
Projector Headlamps	(Bi-Halogen)	(Bi-Halogen)	(Bi-Halogen)	(Bi-Halogen)	(Bi-Halogen)	(Dual LED)	(Dual LED)	(Dual LED)	(Dual LED)	(Dual LED)
Floating LED Day Time Running Lamps
Front Fog Lamps (LED)
Roof Rail
Roof End Spoiler
Chrome Accentuated Front Grille
Rear Combination Lamp (LED)
Shark Fin Antenna
Dual Tone Exterior (In Selected Colours)
Wheel Arch Cladding
Skid Plate (Fr & Rr)	(Black)	(Black)	(Black)	(Black)	(Black)	(Silver)	(Silver)	(Silver)	(Silver)	(Silver)
Side Under Body Cladding
Side Door Cladding

Interiors

	LXI MT	LXI CNG MT	VXI MT	VXI AT	VXI CNG MT	ZXI MT	ZXI AT	ZXI CNG MT	ZXI+ MT	ZXI+ AT
Interior Color Theme	(Mono Tone)	(Mono Tone)	(Mono Tone)	(Mono Tone)	(Mono Tone)	(Dual Tone)	(Dual Tone)	(Dual Tone)	(Dual Tone)	(Dual Tone)
Interior Ambient Lights
Leather Wrapped Steering Wheel^
Co-Driver Side Vanity Lamp
Chrome Plated Inside Door Handles
Door Armrest With Fabric
Luggage Lamp
Glove Box Illumination
Front Footwell Illumination
Cabin Lamp
Flat Bottom Steering Wheel
Rear Parcel Tray
Hook In Luggage Area
IP Ornament	(Black)	(Black)	(Black)	(Black)	(Black)	(Silver)	(Silver)	(Silver)	(Silver)	(Silver)
^Some parts of the leather appointed upholstery will contain man-made material.

Safety

	LXI MT	LXI CNG MT	VXI MT	VXI AT	VXI CNG MT	ZXI MT	ZXI AT	ZXI CNG MT	ZXI+ MT	ZXI+ AT
Head up Display
360 View Camera
Side and Curtain Airbags^^
Shoulder Height Adjustable Front Seat Belts
Electronic Stability Program (ESP)
Hill Hold Assist
Driver & Co-Driver Airbags^^
Rear View Camera
Front Seat Belt Pre-tensioners & Force Limiter
Reverse Parking Sensor with Infographic Display
High Speed Warning Alert#
Seat Belt Reminder Lamp & Buzzer (Driver & Co-Driver)
Rear Wiper & Washer
Rear Defogger (Electric)
Anti-theft Security System
Suzuki TECT Body
Dual Horn
Engine Immobilizer
ISOFIX Child Seat Restraint System
Impact Sensing Door Unlock
Day/Night Rear View Mirror	(Manual)	(Manual)	(Manual)	(Manual)	(Manual)	(Manual)	(Manual)	(Manual)	(Auto)	(Auto)
Door Ajar Warning Lamp
Central Locking	(5 Door)	(5 Door)	(5 Door)	(5 Door)	(5 Door)	(5 Door)	(5 Door)	(5 Door)	(5 Door)	(5 Door)
^^For details on functioning of safety features including air bag, kindly refer to the Owners Manual.
#If the vehicle’s speed exceeds 80 km/h, then the primary level warning will beep twice every minute. And if the vehicle speed goes above 120 km/h, the secondary level warning will keep beeping. If the vehicle speed slows down to 118 km/h, primary warning will resume. If the vehicle is slowed down to 78 km/h, speed alert warning will stop. This buzzer does not include any malfunction in the vehicle.

INFOTAINMENT

	VXI MT	VXI AT	VXI CNG MT	ZXI MT	ZXI AT	ZXI CNG MT	ZXI+ MT	ZXI+ AT
Touch Screen Audio	17.78cm (SmartPlay Studio)	17.78cm (SmartPlay Studio)	17.78cm (SmartPlay Studio)	17.78cm (SmartPlay Pro)	17.78cm (SmartPlay Pro)	17.78cm (SmartPlay Pro)	22.86cm (SmartPlay Pro+)	22.86cm (SmartPlay Pro+)
Premium Sound System				ARKAMYS	ARKAMYS	ARKAMYS	ARKAMYS (Surround Sense)	ARKAMYS (Surround Sense)
Android Auto and Apple CarPlay###				Wireless	Wireless	Wireless	Wireless	Wireless
Remote Control App for Infotainment
Steering Mounted Controls: Audio and Bluetooth
Over the Air Update (OTA)
Onboard Voice Assistant (Wake up through Hi Suzuki with Barge in Feature)
USB & Bluetooth Connectivity
Speakers (4)
Tweeters (2)
MID with TFT Color Display
MID with Segment Display
Speedometer with Tachometer
Audible Headlight On Reminder
Low Fuel Warning Light
Gear Shift Indicator (MT Only)
###Apple and iPhone are trademarks of Apple Inc. registered in the U.S. and other countries. Apple CarPlay is a trademark of Apple Inc., Apple CarPlay is available in the countries listed in the following link: http://www.apple.com/ios/feature-availability/#applecarplay-applecarplay. Apple CarPlay is compatible with the iPhone models listed in the following link: http://www/apple.com/ios/carplay. Android Auto™ extends the Android platform into the car in a way that's purpose-built for driving. It is designed to minimise distraction so you can focus on driving with Google™ services like Google Map™ and Google Search™. Get the Android Auto app on Google Play™. Android Auto is available in the countries listed at the following link: https://www.android.com/auto/#hit-the-road. Most phones with Android 5.0+ work with Android Auto: https://support.google.com/androidauto/#6140477. Android, Android Auto, Google, Google Play and other marks are trademarks of Google Inc.

Comfort & Convenience

	LXI MT	LXI CNG MT	VXI MT	VXI AT	VXI CNG MT	ZXI MT	ZXI AT	ZXI CNG MT	ZXI+ MT	ZXI+ AT
Electric Sunroof
Wireless Charging Dock
Rear Fast Charging USB (Type A and C)
Cruise Control
Height Adjustable Driver Seat
Front Center Armrest (Sliding Type With Storage)
Cooled Glove Box
60:40 Split Seat (Rear)
Overhead Console with Sunglass Holder & Map Lamp
Engine Push Start/stop With Smart Key
Rear Center Armrest With Cup Holder
Adjustable Rear Seat Headrest
Electrically Adjustable ORVM
Electrically Foldable ORVM									(Auto Fold)	(Auto Fold)
Driver Side Front Window (Auto Up/Down)
Rear AC Vents
Auto Climate control
Keyless Entry System
Front & Rear Power Windows
Steering Column Adjustment	(Tilt)	(Tilt)	(Tilt)	(Tilt)	(Tilt)	(Tilt & Telescopic)	(Tilt & Telescopic)	(Tilt & Telescopic)	(Tilt & Telescopic)	(Tilt & Telescopic)
Front Accessory Socket

Colour Variants

	LXI MT	LXI CNG MT	VXI MT	VXI AT	VXI CNG MT	ZXI MT	ZXI AT	ZXI CNG MT	ZXI+ MT	ZXI+ AT
Splendid Silver With Midnight Black Roof (Dual Tone)
Sizzling Red with Midnight Black Roof (Dual Tone)
Brave Khakhi with Arctic White Roof (Dual Tone)
Brave Khakhi
Splendid Silver
Sizzling Red
Exuberant Blue
Pearl Arctic White
Magma Grey

Engine
DIMENSIONS
Transmission
Brakes
Suspension
Tyre

Engine

	LXI MT	LXI CNG MT	VXI MT	VXI AT	VXI CNG MT	ZXI MT	ZXI AT	ZXI CNG MT	ZXI+ MT	ZXI+ AT
Engine Type	K15C Smart Hybrid	K15C	K15C Smart Hybrid	K15C Smart Hybrid	K15C	K15C Smart Hybrid	K15C Smart Hybrid	K15C	K15C Smart Hybrid	K15C Smart Hybrid
Fuel Type	Petrol Mode	CNG Mode	Petrol Mode	Petrol Mode	CNG Mode	Petrol Mode	Petrol Mode	CNG Mode	Petrol Mode	Petrol Mode
Capacity (cc)	1462	1462	1462	1462	1462	1462	1462	1462	1462	1462
Max Power (kW @ RPM)	75.8 @ 6000	74.0 @ 6000 (Gasoline) 64.6 kW @ 5500	75.8 @ 6000	75.8 @ 6000	74.0 @ 6000 (Gasoline) 64.6 kW @ 5500	75.8 @ 6000	75.8 @ 6000	74.0 @ 6000 (Gasoline) 64.6 kW @ 5500	75.8 @ 6000	75.8 @ 6000
Max Torque (Nm @ RPM)	136.8 @ 4400	136.0 @ 4400 (Gasoline) 121.5 Nm @ 4200	136.8 @ 4400	136.8 @ 4400	136.0 @ 4400 (Gasoline) 121.5 Nm @ 4200	136.8 @ 4400	136.8 @ 4400	136.0 @ 4400 (Gasoline) 121.5 Nm @ 4200	136.8 @ 4400	136.8 @ 4400
Emission Type	BS VI	BS VI	BS VI	BS VI	BS VI	BS VI	BS VI	BS VI	BS VI	BS VI
Fuel Efficiency	20.15 km/l	25.51 km/kg	20.15 km/l	19.80 km/l	25.51 km/kg	19.89 km/l	19.80 km/l	25.51 km/kg	19.89 km/l	19.80 km/l
Fuel Tank Capacity (L)	48	Petrol: 48 CNG: 55 (Water Equivalent)	48	48	Petrol: 48 CNG: 55 (Water Equivalent)	48	48	Petrol: 48 CNG: 55 (Water Equivalent)	48	48
Idle Start Stop
Brake Energy Regeneration
Torque Assist During Acceleration

Dimensions

	LXI MT	LXI CNG MT	VXI MT	VXI AT	VXI CNG MT	ZXI MT	ZXI AT	ZXI CNG MT	ZXI+ MT	ZXI+ AT
Length(mm)	3995	3995	3995	3995	3995	3995	3995	3995	3995	3995
Width(mm)	1790	1790	1790	1790	1790	1790	1790	1790	1790	1790
Height (unladen) (mm)	1685	1685	1685	1685	1685	1685	1685	1685	1685	1685
Wheelbase (mm)	2500	2500	2500	2500	2500	2500	2500	2500	2500	2500
Seating capacity	5	5	5	5	5	5	5	5	5	5
Boot Space (L)	328*		328*	328*		328*	328*		328*	328*
*VDA Method.

Transmission

	LXI MT	LXI CNG MT	VXI MT	VXI AT	VXI CNG MT	ZXI MT	ZXI AT	ZXI CNG MT	ZXI+ MT	ZXI+ AT
Transmision	5 MT / 6AT	5 MT	5 MT / 6AT	5 MT / 6AT	5 MT	5 MT / 6AT	5 MT / 6AT	5 MT	5 MT / 6AT	5 MT / 6AT

Brakes

	LXI MT	LXI CNG MT	VXI MT	VXI AT	VXI CNG MT	ZXI MT	ZXI AT	ZXI CNG MT	ZXI+ MT	ZXI+ AT
Front	Ventilated Disc	Ventilated Disc	Ventilated Disc	Ventilated Disc	Ventilated Disc	Ventilated Disc	Ventilated Disc	Ventilated Disc	Ventilated Disc	Ventilated Disc
Rear	Drum	Drum	Drum	Drum	Drum	Drum	Drum	Drum	Drum	Drum

Suspension

	LXI MT	LXI CNG MT	VXI MT	VXI AT	VXI CNG MT	ZXI MT	ZXI AT	ZXI CNG MT	ZXI+ MT	ZXI+ AT
Front	Mac Pherson Strut & Coil	Mac Pherson Strut & Coil	Mac Pherson Strut & Coil	Mac Pherson Strut & Coil	Mac Pherson Strut & Coil	Mac Pherson Strut & Coil	Mac Pherson Strut & Coil	Mac Pherson Strut & Coil	Mac Pherson Strut & Coil	Mac Pherson Strut & Coil
Rear	Torsion Beam & Coil Spring	Torsion Beam & Coil Spring	Torsion Beam & Coil Spring	Torsion Beam & Coil Spring	Torsion Beam & Coil Spring	Torsion Beam & Coil Spring	Torsion Beam & Coil Spring	Torsion Beam & Coil Spring	Torsion Beam & Coil Spring	Torsion Beam & Coil Spring

Tyre

	LXI MT	LXI CNG MT	VXI MT	VXI AT	VXI CNG MT	ZXI MT	ZXI AT	ZXI CNG MT	ZXI+ MT	ZXI+ AT
Tyre Size	215/60 R16##	215/60 R16##	215/60 R16##	215/60 R16##	215/60 R16##	215/60 R16##	215/60 R16##	215/60 R16##	215/60 R16##	215/60 R16##
##Spare wheel material is steel & spare tyre size is 215/60 R16.

WagonR

Interiors
Instrument Cluster
Comfort and Convenience
Infotainment System
Safety and Security
Exteriors

Interiors

	LXI 1.0L	LXI CNG 1.0L	VXI 1.0L	VXI AGS 1.0L	VXI CNG 1.0L	ZXI 1.2L	ZXI AGS 1.2L	ZXI+ 1.2L	ZXI+ AGS 1.2L
Dual Tone Interiors
2^nd Row 60:40 Split Seat
Front Cabin Lamps (3 Positions)
Day/Night IRVM
Tilt Steering
Steering Wheel Garnish
Silver Inside Door Handles
Driver Side Sunvisor with Ticket Holder
Front Passenger Side Vanity Mirror Sunvisor
Silver Finish Gear Shift Knob (AGS only)

Instrument Cluster

	LXI 1.0L	LXI CNG 1.0L	VXI 1.0L	VXI AGS 1.0L	VXI CNG 1.0L	ZXI 1.2L	ZXI AGS 1.2L	ZXI+ 1.2L	ZXI+ AGS 1.2L
Instrument Cluster Meter Theme	Reddish Amber	Reddish Amber	Reddish Amber	Reddish Amber	Reddish Amber	Reddish Amber	Reddish Amber	White	White
Low Fuel Warning
Tachometer
Gear Shift Indicator (MT Only)
Gear Position Indicator (AGS Only)
Fuel Consumption (Instantaneous and Average)
Distance to empty
Headlamp On Warning
Door Ajar Warning Lamp

Comfort and Convenience

	LXI 1.0L	LXI CNG 1.0L	VXI 1.0L	VXI AGS 1.0L	VXI CNG 1.0L
Idle Start Stop(ISS)	(Petrol)	(Petrol)	(Petrol)	(Petrol)	(Petrol)
Remote Keyless Entry
Accessory Socket Front Row with Storage Space
Power Windows (Fr/Rr) with Dr. Slide Auto Down Function	Only Front	Only Front
AC & Heater
1L Bottle Holders (All Four Doors + Floor Console)
Rear Parcel Tray	CNG Only	CNG Only
Co. Driver Side Front Seat Under Tray and Rear Back Pocket
Reclining & Front Sliding Seats

Infotainment System

	VXI 1.0L	VXI AGS 1.0L	VXI CNG 1.0L	ZXI 1.2L	ZXI AGS 1.2L	ZXI+ 1.2L	ZXI+ AGS 1.2L
17.78 cm Smartplay Studio with Smartphone Navigation
Smartplay Dock
Apple Carplay and Android Auto
Bluetooth
Number of Speakers	2	2	2	2	2	4	4
USB Connectivity/AUX
Steering Mounted Audio Control
Steering Mounted Voice Control

Safety And Security

	VXI 1.0L	VXI AGS 1.0L	VXI CNG 1.0L	ZXI 1.2L	ZXI AGS 1.2L	ZXI+ 1.2L	ZXI+ AGS 1.2L
Driver Airbag^##
Passenger Airbag
ABS with EBD
Electronic Stability Program (ESP)
Seat Belt Pre-tensioner and Force Limiters (Dr.+Co-Dr.)
Seat Belt Reminder with Buzzer (Front & Rear Seat)^{^^#}
Seat Belts for all seats^{^^^}
Speed Alert System^{^^}
Speed Sensitive Auto Door Lock
Security Alarm
Rear Parking Sensors
Central Locking
Child Proof Rear Door Lock
Front Fog Lamps
Hill Hold Assist	AGS	AGS	AGS	AGS	AGS	AGS	AGS
##For details on functioning of safety features, including air bag, kindly refer to the Owner's Manual.
^^#Seat belt reminder comes on unless all rear passenger's seat belts are fastened irrespective of the presence or absence of passenger.
^^^Rear Centre seat has lap belt type of seat belt.
^^The speed alert system gives audible warning for alert of over-speed to driver. When the vehicle speed exceeds about 80km/h, primary level warning with two beeps will sound every minute. When the vehicle speed exceeds about 120km/h, secondary level warning with continuous beeps will sound. If the vehicle speed is slowed down to about 118km/h, primary warning will resume. If the vehicle is slowed down to 78km/h, speed alert warning will stop. This buzzer does not indicate any malfunction in vehicle.

Exteriors

	LXI 1.0L	LXI CNG 1.0L	ZXI+ 1.2L	ZXI+ AGS 1.2L
Roof Antenna
Full Wheel Cover	(Center Cap)	(Center Cap)
Alloy Wheels
ORVM with Turn Indicators
Electrical Adjustable ORVM
Electrical Retractable ORVM
Rear Wiper and Washer
B-Pillar Black Out Tape
Body Coloured Door Handles
Body Coloured Bumpers
Body Coloured ORVMs			(Black In Dual tone)	(Black in Dual Tone)
Dual Tone Exteriors			(Optional)	(Optional)

Dimensions
Engine & Transmission
Suspension
Capacities
Wheels and Tyres
Brakes
Weight

DIMENSIONS

	LXI 1.0L	LXI CNG 1.0L	VXI 1.0L	VXI AGS 1.0L	VXI CNG 1.0L	ZXI 1.2L	ZXI AGS 1.2L	ZXI+ 1.2L	ZXI+ AGS 1.2L
Length (mm)	3655	3655	3655	3655	3655	3655	3655	3655	3655
Width (mm)	1620	1620	1620	1620	1620	1620	1620	1620	1620
Height (mm)	1675	1675	1675	1675	1675	1675	1675	1675	1675
Wheelbase (mm)	2435	2435	2435	2435	2435	2435	2435	2435	2435
Turning Radius (m)	4.7	4.7	4.7	4.7	4.7	4.7	4.7	4.7	4.7

Engine & Transmission

	LXI 1.0L	LXI CNG 1.0L	VXI 1.0L	VXI AGS 1.0L	VXI CNG 1.0L	ZXI 1.2L	ZXI AGS 1.2L	ZXI+ 1.2L	ZXI+ AGS 1.2L
Type	K10C	K10C	K10C	K10C	K10C	K12N	K12N	K12N	K12N
Capacity (cc)	998	998	998	998	998	1197	1197	1197	1197
Number of Cylinders	3	3	3	3	3	4	4	4	4
Maximum engine output(kW @ rpm)	49.0 kW (66.62 PS) @ 5500 rpm	41.7 kW (56.70 PS) @ 5300 rpm (CNG mode) 48.0 kW (65.26 PS) @ 5500 rpm (Petrol mode)	49.0 kW (66.62 PS) @ 5500 rpm	49.0 kW (66.62 PS) @ 5500 rpm	41.7 kW (56.70 PS) @ 5300 rpm (CNG mode) 48.0 kW (65.26 PS) @ 5500 rpm (Petrol mode)	66 kW (89.73 PS) @ 6000 rpm	66 kW (89.73 PS) @ 6000 rpm	66 kW (89.73 PS) @ 6000 rpm	66 kW (89.73 PS) @ 6000 rpm
Maximum torque (Nm @ rpm)	89.0 Nm @ 3500 rpm	82.1 Nm @ 3400 rpm (CNG mode) 89.0 Nm @ 3500 rpm (Petrol mode)	89.0 Nm @ 3500 rpm	89.0 Nm @ 3500 rpm	82.1 Nm @ 3400 rpm (CNG mode) 89.0 Nm @ 3500 rpm (Petrol mode)	113 Nm @ 4400 rpm	113 Nm @ 4400 rpm	113 Nm @ 4400 rpm	113 Nm @ 4400 rpm
Transmission	MT	MT	MT	AGS	MT	MT/AGS	AGS	MT/AGS	AGS

Suspension

	LXI 1.0L	LXI CNG 1.0L	VXI 1.0L	VXI AGS 1.0L	VXI CNG 1.0L	ZXI 1.2L	ZXI AGS 1.2L	ZXI+ 1.2L	ZXI+ AGS 1.2L
Front	MacPherson Strut with Coil Spring	MacPherson Strut with Coil Spring	MacPherson Strut with Coil Spring	MacPherson Strut with Coil Spring	MacPherson Strut with Coil Spring	MacPherson Strut with Coil Spring	MacPherson Strut with Coil Spring	MacPherson Strut with Coil Spring	MacPherson Strut with Coil Spring
Rear	Torsion Beam with Coil Spring	Torsion Beam with Coil Spring	Torsion Beam with Coil Spring	Torsion Beam with Coil Spring	Torsion Beam with Coil Spring	Torsion Beam with Coil Spring	Torsion Beam with Coil Spring	Torsion Beam with Coil Spring	Torsion Beam with Coil Spring

Capacities

	LXI 1.0L	LXI CNG 1.0L	VXI 1.0L	VXI AGS 1.0L	VXI CNG 1.0L	ZXI 1.2L	ZXI AGS 1.2L	ZXI+ 1.2L	ZXI+ AGS 1.2L
Seating Capacity	5	5	5	5	5	5	5	5	5
Fuel Tank Capacity (L)	32 (Petrol)/ 60 (Water equivalent)	32 (Petrol)/ 60 (Water equivalent)	32 (Petrol)/ 60 (Water equivalent)	32 (Petrol)/ 60 (Water equivalent)	32 (Petrol)/ 60 (Water equivalent)	32 (Petrol)	32 (Petrol)	32 (Petrol)	32 (Petrol)
Boot Space (Litres)	341^ (Petrol)	341^ (Petrol)	341^ (Petrol)	341^ (Petrol)	341^ (Petrol)	341^ (Petrol)	341^ (Petrol)	341^ (Petrol)	341^ (Petrol)
^VDA Method.

Wheels and Tyres

	LXI 1.0L	LXI CNG 1.0L	VXI 1.0L	VXI AGS 1.0L	VXI CNG 1.0L	ZXI 1.2L	ZXI AGS 1.2L	ZXI+ 1.2L	ZXI+ AGS 1.2L
Size	155/80R13	155/80R13	165/70R14	165/70R14	165/70R14	165/70R14	165/70R14	165/70R14	165/70R14
Type**	Radial & Tubeless, Steel Wheels	Radial & Tubeless, Steel Wheels	Radial & Tubeless, Steel Wheels	Radial & Tubeless, Steel Wheels	Radial & Tubeless, Steel Wheels	Radial & Tubeless, Steel Wheels	Radial & Tubeless, Steel Wheels	Radial & Tubeless, Alloy Wheels	Radial & Tubeless, Alloy Wheels
**Spare Wheel Material is steel(for all variants).

Brakes

	LXI 1.0L	LXI CNG 1.0L	VXI 1.0L	VXI AGS 1.0L	VXI CNG 1.0L	ZXI 1.2L	ZXI AGS 1.2L	ZXI+ 1.2L	ZXI+ AGS 1.2L
Front	Disc	Disc	Disc	Disc	Disc	Disc	Disc	Disc	Disc
Rear	Drum	Drum	Drum	Drum	Drum	Drum	Drum	Drum	Drum

Weight

	LXI 1.0L	LXI CNG 1.0L	VXI 1.0L	VXI AGS 1.0L	VXI CNG 1.0L	ZXI 1.2L	ZXI AGS 1.2L	ZXI+ 1.2L	ZXI+ AGS 1.2L
Gross Vehicle Weight (kg)	1340	1340	1340	1340	1340	1340	1340	1340	1340
Kerb Weight (kg)	810	910	825	835	920	835	840	845	850

Alto

Ex-showroom Price

Mileage

Petrol - 22.05 km/l* CNG - 31.59 km/kg#

*For Petrol Variants only. #In CNG mode CNG variants only. As certified by Test Agency Under Rule 115 (G) of CMVR 1989

download brochure

Features
Technical Specifications

SAFETY
COMFORT & CONVENIENCE
INSTRUMENTS CLUSTER
INTERIOR & SEAT
EXTERIOR

SAFETY

	LX	LXI	LXI CNG	VXI	VXI (O)	VXI AGS
Driver Airbag
Reverse parking Sensor
Seat Belt Reminder - Dr+ Co Dr
Speed Alert System
Front Fog Lamps	-	-	-	-
Front Seat Belt: 3-point ELR Seat Belts
Rear Seat Belt 3-point ELR SeatBelts x 2
2-point Fix Seat Belt x 1			-
High Mounted Stop Lamp
Front Disc Brake	Ventilated	Ventilated	Ventilated	Ventilated	Ventilated	Ventilated
Child - Proof Rear Door Locks

COMFORT & CONVENIENCE

	LX	VXI	VXI (O)	VXI AGS
Air Conditioner
Power Steering
Audio (CD-MP3-USB,RADIO)
Antenna
Number of Speakers		2	2	2
Keyless Entry				_
Central Door Locking
Tailgate Opener
Front Power Window
Key off Audible Reminder
Head Lamp on Warning Buzzer
Internally Adjustable ORVM	_
Rear Parcel Tray

Instruments Cluster

	LX	LXI	LXI CNG	VXI	VXI (O)	VXI AGS
Tachometer
Shift Up Indicator
Gear Shift Digital Display (Auto Gear Shift)
Accessory Socket
Digital Clock
Dial-type Climate Control

INTERIOR & SEAT

	LX	LXI	LXI CNG	VXI	VXI (O)	VXI AGS
Sun Visor (Dr+Co-Dr)
Vanity Mirrors				( Co-Dr)	( Co-Dr)	( Co-Dr)
Cabin Light (3-Position)	( Front)	( Front)	( Front)	( Front)	( Front)	( Front)
Floor Console with 2 Cup Holders
Piano Black Finish I/P Center Garnish
Silver Accent (Side Louvers, Steering Wheel,Inside Door Handle, Console Garnish Ring, Panel Instrument cluster garnish,Door trim armrest)

EXTERIOR

	LX	LXI	LXI CNG	VXI	VXI (O)	VXI AGS
Chrome Front Grille
Body Coloured Bumper
Body Coloured Door Mirror
Body Coloured Outside Door Handles
B Pillar Black-Out Tape
Full Wheel Covers
Body Side Molding

Brakes
Capacity
Dimension
Engine
Suspension System
Weight

Brakes

	LX	LXI	LXI CNG	VXI	VXI (O)	VXI AGS
Front	Ventilated Disk	Ventilated Disk	Ventilated Disk	Ventilated Disk	Ventilated Disk	Ventilated Disk
Rear	Drum	Drum	Drum	Drum	Drum	Drum

Capacity

	LX	LXI	LXI CNG	VXI	VXI (O)	VXI AGS
Seating	5 Persons	5 Persons	4 Persons	5 Persons	5 Persons	5 Persons
Fuel Tank Capacity	35 L (Gasoline)	35 L (Gasoline)	60 L (Water Equivalent Capacity - CNG)	35 L (Gasoline)	35 L (Gasoline)	35 L (Gasoline)

Dimensions

	LX	LXI	LXI CNG	VXI	VXI (O)	VXI AGS
Overall Length	3545 mm	3545 mm	3545 mm	3545 mm	3545 mm	3545 mm
Overall Width (without Body Side Moulding)	1490 mm	1490 mm	1490 mm	1490 mm	1490 mm	1490 mm
Overall Width (with Body Side Moulding)	1515 mm	1515 mm	1515 mm	1515 mm	1515 mm	1515 mm
Overall Height	1475 mm	1475 mm	1475 mm	1475 mm	1475 mm	1475 mm
Tread (Front)	1295 mm	1295 mm	1295 mm	1295 mm	1295 mm	1295 mm
Tread (Rear)	1290 mm	1290 mm	1290 mm	1290 mm	1290 mm	1290 mm
Turning Radius	4.6 m	4.6 m	4.6 m	4.6 m	4.6 m	4.6 m
Wheelbase	2360 mm	2360 mm	2360 mm	2360 mm	2360 mm	2360 mm

Engine

	LX	LXI	LXI CNG	VXI	VXI (O)	VXI AGS
Fuel	GASOLINE	GASOLINE	CNG + GASOLINE	GASOLINE	GASOLINE	GASOLINE
Transmission	5MT	5MT	5MT	5MT	5MT	AMT
Emission Type	BS IV + OBD II	BS IV + OBD II	BS IV + OBD II	BS IV + OBD II	BS IV + OBD II	BS IV + OBD II
Maximum Torque	90 Nm 3500 rpm (Gasoline)	90 Nm 3500 rpm (Gasoline)	78 Nm 3500 rpm (CNG)	90 Nm 3500 rpm (Gasoline)	90 Nm 3500 rpm (Gasoline)	90 Nm 3500 rpm (Gasoline)
Engine (Cubic Capacity)	K10B (998cc)	K10B (998cc)	K10B (998cc)	K10B (998cc)	K10B (998cc)	K10B (998cc)
Maximum Power	50 kW 6000 rpm (Gasoline)	50 kW 6000 rpm (Gasoline)	43.5 kW 6000 rpm (CNG)	50 kW 6000 rpm (Gasoline)	50 kW 6000 rpm (Gasoline)	50 kW 6000 rpm (Gasoline)

Suspension System

	LX	LXI	LXI CNG	VXI	VXI (O)	VXI AGS
Front	Gas Filled MacPherson Strut	Gas Filled MacPherson Strut	Gas Filled MacPherson Strut	Gas Filled MacPherson Strut	Gas Filled MacPherson Strut	Gas Filled MacPherson Strut
Rear	3 Link Rigid Axle Suspension	3 Link Rigid Axle Suspension	3 Link Rigid Axle Suspension	3 Link Rigid Axle Suspension	3 Link Rigid Axle Suspension	3 Link Rigid Axle Suspension
Tyre Size	155/65 R13	155/65 R13	155/65 R13	155/65 R13	155/65 R13	155/65 R13

Weight

	LX	LXI	LXI CNG	VXI	VXI (O)	VXI AGS
Gross Weight	1210 Kg	1210 Kg	1210 Kg	1210 Kg	1210 Kg	1210 Kg
Kerb Weight	769 Kg	774 Kg	867 Kg	779 Kg	784 Kg	784 Kg

Get A Quote

Get A Quote+

About Us
Know Our Dealership

about us

Authorized Dealership Of Maruti Suzuki India Limited , Always Respect Customer , All Test Drive Vehicle Available , State Of Art Showroom. We also offer insurance renewal and accessories to service all your needs.we strongly believe that it is THE AFTER SALES SERVICE WHICH counts.Which means we believe that your car owning journey not only starts after you buy the car but we will be with you,every step of the way.The Dealership's are run by Professional Managers ably assisted by over 5,500 qualified and committed personnel. Sai Service has paid great attention to detail in creating an atmosphere that is welcoming and comfortable. We are dedicated to enhancing every aspect of the customer experience.from their initial visit to long after they have purchase the car of dreams.

Know us

Welcome to , Maruti Suzuki ARENA showroom at in Virar where you will find the complete range of Maruti Suzuki cars, including Hatchback, Sedan, Suv or Van. As a reputed car dealership in Virar, , focuses on delivering a great car buying experience.

When you search for a ‘Maruti Suzuki car dealership near me’, you can rest assured that at in Virar will provide you with all the information and assistance you need to make a well-researched choice.

From exploring a wide range of accessories to the highest value offers, visit and check out the range of cars – from Dzire or Swift or Wagon R or Alto or Alto K10 to Celerio or S-presso or Ertiga or Brezza or Eeco in Virar along with on-road price and loan EMI.
Look through the Hatchback, Sedan, Suv or Van at our Maruti Suzuki ARENA outlet to book a test drive and book your favourite car today!

You can also visit the digital showroom of , Maruti Suzuki ARENA in . Filter your search as per your preferences for the Dzire or Swift or Wagon R or Alto or Alto K10 or Celerio or S-presso or Ertiga or Brezza or Eeco of your choice. Avail of these services online when you buy your new Maruti Suzuki ARENA car. You can also check out the latest offers & discounts and the wide range of accessories being offered at Maruti Suzuki ARENA.

Our Team

Mr. Jitendra Khamkar

Sales Manager

CONTACT US

Virar West

Maruti Suzuki Arena, Virar West
Sai Service Pvt. Ltd.
Shop No- 8,9 & 10 Viva Gokul Arcade, Agashi Road, Bolinj, Next to Axis Bank, Virar West, Palghar, Maharashtra - 401303
headvirar@saiservice.com

OPENING HOURS

Mon - Sun : 09:30 AM - 08:00 PM

customer testimonials

Good Showroom, excellent customer service and cooperative staffs.

Saurabh Dubey

Virar West, Palghar

Well maintained staff,easy loan finance. All suzuki cars available I would like to thank the staffs for best service.

Sonali Kamble

Virar West, Palghar

I would like to thank my customer executive from Sai Services for his excellent customer service that his has given. Communication and transaction was very smooth. All in all I would rate my experience as 10 stars .

Adeline Austin

Virar West, Palghar

I want say that your service is really Appreciatetable. I feel very happy at this time. The service which u provided that's really Great service. I just say thank to staffs because they helped us a very lot. So thanks for Good service!

Vishal Kolapkar

Virar West, Palghar
